Image of the Week: Icequakes! Stick-Slip motion under Western Greenland

Image of the Week: Icequakes! Stick-Slip motion under Western Greenland
The Greenland Ice Sheet contains enough fresh water to raise global sea level by around 6 m, therefore it is very important to understand how the ice moves from the interior of the ice sheet towards the oceans. Processes that happen at the base of the ice sheet, where the ice meets the bed, are known to be a key control on how the ice moves. Geophysical techniques, such as recording tiny icequakes that happen as the ice moves over it’s bed, can be used to investigate the basal dynamics that accommodate this movement.

A new study of icequakes recorded in the ablation zone on the West coast of the Greenland Ice Sheet show that in this region the ice sheet moves by stick-slip behaviour at its base, with concurrent emissions of seismic energy. More than 11,000 icequakes have been detected and located at the base of the ice sheet. The waveforms of the icequakes observed at several seismic stations show that some stations record waveforms with upwards first motions (compression) and some stations downwards first motions (dilation). This corresponds to a stick-slip fault mechanism, where the ice is sliding over its bed and causing icequakes as it sticks and then slips. This type of seismic evidence for stick-slip motion has been observed in several Antarctic ice streams, but this study documents the first seismic evidence of stick-slip motion of the Greenland Ice Sheet. This seismic signature indicates that the ice moves not only continuously over its bed but also moves coseismically. Giving further insight into the mechanics of movement at the base of the Greenland Ice Sheet. These finding provide important information which will help predict the future evolution of ice sheet flow in Western Greenland.

The image was provided by C. Roeoesli from a study performed as part of her Ph.D. at ETH Zurich, she can now be found at the Swiss Space Center. The full publication was accepted in the Journal of Geophysical Research: Earth Surface earlier this month and can be found here:

Roeoesli, C., A. Helmstetter, F. Walter, and E. Kissling (2016), Meltwater influences on deep stick-slip icequakes near the base of the Greenland Ice Sheet, J. Geophys. Res. Earth Surf., 121, doi:10.1002/2015JF003601.

Emma C. Smith
Emma is a Postdoc at the Alfred Wegener Institute in Germany, using geophysics to investigate ice dynamics in East Antarctica. Prior to that she studied at The British Antarctic Survey and University of Cambridge. She is interested in all things icy and geophysical, especially when they involve fieldwork and is the current ECS Rep for the EGU Crysophere Division. She tweets as @emma_c_smith
