Imaggeo on Mondays: How erosion creates natural clay walls

Imaggeo on Mondays: How erosion creates natural clay walls

The badlands valley of Civita di Bagnoregio is a hidden natural gem in the province of Viterbo, Italy, just 100 kilometres from Rome. Pictured here is the ‘wall,’ one of the valley’s most peculiar features, where you can even find the wooden structural remains of a trail used for agricultural purposes in the 19th and 20th centuries.

The photograph was taken by Chiara Arrighi, a post-doc research assistant at the University of Florence (Italy), in May last year after climbing roughly 200 metres from the bottom of the Chiaro creek valley. Trails in this region are not well traced or maintained, so she had to find her own way up among the chestnut woods. Once at the top, the trail becomes narrow and unprotected. “The inhabitants of the area still do not exploit this natural beauty as a tourist attraction,” said Arrighi. “In fact, nobody was on the trail, and the silence [was] unreal.”

Badlands are a typical geological formation, where grains of sand, silt and clay are clumped together with sedimentary rock to form layers, which are then weathered down by wind and water. The terrain is characterised by erosive valleys with steep slopes, without vegetation, separated by thin ridges.

Due to the slope’s steep angle and the clay’s low permeability, little water is able enter the soil. Instead water quickly flows across the surface, removing surface clay and carving into the slopes as it does so.

The morphological evolution of the clay slopes can be very rapid (for example, rock falls can occur quite suddenly after heavy rainfall) and occurs as a result of several physical mechanisms, such as mud flows, solifluction (slow movement of wet soil towards the bottom of the valley) and sliding.

During the evolution of the badlands, peripheral portions of the terrain made up of volcanic deposits (tuff cliffs) rose up from the landscape, bordered by nearly vertical slopes (called scarps). Many towns have been built on these erected hilltops, such as Civita di Bagnoregio.

By Chiara Arrighi and Olivia Trani

Imaggeo is the EGU’s online open access geosciences image repository. All geoscientists (and others) can submit their photographs and videos to this repository and, since it is open access, these images can be used for free by scientists for their presentations or publications, by educators and the general public, and some images can even be used freely for commercial purposes. Photographers also retain full rights of use, as Imaggeo images are licensed and distributed by the EGU under a Creative Commons licence. Submit your photos at http://imaggeo.egu.eu/upload/.

Imaggeo on Mondays: Corno Grande, tallest peak of the Apennines

Imaggeo on Mondays: Corno Grande, tallest peak of the Apennines

In the middle of the Apennines lays the Gran Sasso d’Italia mountain chain, a picturesque collection of mountains situated in the heart of Italy.

Featured here is one of the chain’s peaks, called the Corno Grande, meaning ‘Big Horn,’ coloured with a faint reddish light of a late-winter sunset. Sitting at 2,912 metres, this summit is easily the highest mountain in the Apennines.

The areas surrounding Corno Grande is enclosed in the Gran Sasso e Monti della Laga National Park, located in the hinterland of Italy’s Abruzzo region. The park, established in 1991, encompasses 2,015 square kilometres, making it one of the largest natural reserves in Europe.

Moreover, from an ecological standpoint, the region is one of the most biologically diverse areas in Europe, with more than 2,000 plant species, many of which can only be found in the park, and many rare animals.

The landscape that surrounds Corno Grande still shows traces of glacial erosion from the Quaternary Period, which began 2.6 million years ago. The region’s smooth highlands and U-shaped valleys are engravings of the slow glacial processes that occurred on these lands. The Corno Grande is even still host to a glacier today, as you can find the Calderone glacier, Western Europe’s southernmost glacier, beneath the mountain’s peak.

Sketch of the geodynamic setting of the Gran Sasso (Credit: Cardello and Doglioni, 2015)

The Apennine Mountains were built by a paradoxical geologic process, sometimes referred to as ‘syn-orogenic extension,’ where thickened crust spreads out while, at the same time, a belt of Earth’s crust is compressed, forming a chain of mountains. In the case of the Apennines, compression took place east of the range while extension occurred to the west.

“This synchronous processes of such different motions in the convergent belts is still an issue that must be unraveled for a better understanding of the mountain ridge formation,” said Alex Righetti, a PhD student studying marine geology at the Faculty of Sciences of the University of Lisbon, in Portugal, who captured this shot.

By Olivia Trani, EGU Communications Officer and Alex Righetti, FCUL

Imaggeo is the EGU’s online open access geosciences image repository. All geoscientists (and others) can submit their photographs and videos to this repository and, since it is open access, these images can be used for free by scientists for their presentations or publications, by educators and the general public, and some images can even be used freely for commercial purposes. Photographers also retain full rights of use, as Imaggeo images are licensed and distributed by the EGU under a Creative Commons licence. Submit your photos at http://imaggeo.egu.eu/upload/.

Imaggeo On Mondays: Reservoir in the Italian Alps

Imaggeo On Mondays: Reservoir in the Italian Alps

Mountain natural streams and reservoirs have a relevant hydrological and ecological importance since they represent reliable sources of freshwater supply to lowland regions and high-quality habitats for fish and cold-water communities. Moreover, streams in mountain environments are of significant importance for users in several socio-economic sectors, such as agriculture, tourism and hydropower.

Given the vulnerability of mountain streams and catchments to the impact of climate changes and the increasing concern about water supply in mountain regions, there is the urgent need for scientists to face integrated, multidisciplinary catchment-scale studies addressing implications of climate change on water resources management and flow regimes.

Description by Daniele Penna, as it first appeared on imaggeo.egu.eu

Imaggeo is the EGU’s online open access geosciences image repository. All geoscientists (and others) can submit their photographs and videos to this repository and, since it is open access, these images can be used for free by scientists for their presentations or publications, by educators and the general public, and some images can even be used freely for commercial purposes. Photographers also retain full rights of use, as Imaggeo images are licensed and distributed by the EGU under a Creative Commons licence. Submit your photos at http://imaggeo.egu.eu/upload/.

Imaggeo on Mondays: Winter threatens to freeze over fieldwork

Imaggeo on Mondays: Winter threatens to freeze over fieldwork

This photo was taken during a fieldwork campaign following the mainshock of the deadly seismic sequence that struck central Italy starting from 24 August 2016. The magnitude 6.2 earthquake severely damaged nearby towns, claimed more than 290 lives and injured nearly 400 people in its wake.

As a geologist from the National Institute of Geophysics and Volcanology, I was in charge of measuring the manifestations of the seismic shaking (mainly fractures and landslides) on the territory. Some of the most relevant fractures were located along the mountain ridge formed by Monte Vettore (in the background of the photo) and Monte Porche (on which the photo was taken).

The new snow and the lowering temperature signaled that winter was approaching. The changing season also meant that my colleagues and I would have to rush the survey before the snow buried even the deepest fractures.

By Roberto Vallone, a technologist at the National Institute of Geophysics and Volcanology in Italy
