Iceland’s rootless volcanoes

Iceland’s rootless volcanoes

Picture a volcano, like the one you learned about in primary school. Can you see it? Is it a big rocky mountain, perhaps with a bubbling pool of lava at the top? Is it perched above a chasm of subterranean molten rock?

I bet you didn’t picture this:

Rootless cones in the Lanbrotshólar district, S Iceland. Created by the 940AD Eldgjá eruption, there are over 4000 rootless cones in this area. Credit: Frances Boreham

You’d be forgiven for mistaking these small volcanoes for a scene from the Lord of the Rings, or maybe a grassy version of the surface of Mars (in fact, these kind of volcanoes do occur on Mars). These, however, are in Iceland and are called rootless cones.

These mini-volcanoes are unusual because they are ‘rootless’ meaning, unlike most volcanoes, they are not fed from the underground. To make them even stranger, they erupted only once and as part of the same event.

This type of volcanism is observed in several places around the world and occurs only in a unique set of circumstances. Despite showing similarities to more traditional volcanoes (like pyroclastic cones), the cones pictured above actually erupted several tens of kilometres from a ‘true’ volcano.

Rootless cones occur when a hot lava flow produced by an eruption travels away from the volcano and meets water. This can be a lake, a river, a glacier or simply a bit of soggy ground. The only criteria are that there needs to be water, and it needs to be trapped. Lava flows are usually at temperatures of over 1000oC and so, when they come into contact with trapped water or ice, its causes a build-up of steam, which can explode violently through the lava forming a rootless cone.

An article, published in the Journal of Volcanology and Geothermal Research in September by volcanologists from the University of Bristol and the University of Iceland, analysed the shape and location of some of these cones to understand more about the environment in which they formed.

These features are found in northeast Iceland in the region around lake Mývatn. The area, 50 km east of the city of Akureyri, is world famous for its beautiful scenery and unusual landscapes.

The volcano responsible for the phenomena is the Þrengslaborgir–Lúdentsborgir crater row which erupted around 2000 years ago. The eruption produced a huge lava flow that covered an area of 220 km2; over 2% of the surface of Iceland. The flow, known as the Younger Laxá Lava, permanently changed the landscape, diverting rivers and damming lakes. After its extrusion from the volcano, the stream of molten rock meandered through different environments including river gorges and wide glacial valleys.

The flow’s diverse 67km journey allowed lead author Frances Boreham and her colleagues, to learn how it interacted with its surroundings. As she explains it, “one of the things that makes the Younger Laxá Lava such a great case study is the range of environments that the lava flowed through.”

Rootless cones do not all look the same and vary greatly in size, from small ‘hornitos’ which are about the size of a small car, to large crater-shaped cones hundreds of metres in size. The scale and complexity of the deposits makes them difficult to study as Boreham explains, “One of the biggest challenges is trying to understand and unpick the different effects of lava and water supply on rootless eruptions. We see a huge variety in rootless cone shapes and sizes, but working out which aspects are controlled by the lava flow and which by the environment and available water is tricky, especially when working on a lava flow that’s approximately 2000 years old!”

From Boreham et al. 2016. “Different types of rootless cone and associated features. a) Scoriaceous rootless cone at Skutustaðir, Mývatn. Cone base is ~100 m diameter. b) Explosion pits (marked with arrows) surrounding a scoriaceous rootless cone near Mývatn. c) Spatter cone at Mý d) Hornito in Aðaldalur, NE Iceland. Map imagery on d ©2017 DigitalGlobe, Google.” Licensed under creative commons.

Despite their beauty, the rootless cones represent a more serious issue. Lava flows are often thought of as quite benign compared to other volcanic hazards like pyroclastic flows. The presence of rootless cones suggests this isn’t always the case. “As far as I know, none of these rootless cones are currently taken into account for lava flow hazard assessments, in Iceland or elsewhere in the world. While not applicable everywhere, wet environments with a history of lava flows, such as Iceland or parts of the Cascades, could be affected and these hazards should be considered in future risk assessments and plans, e.g. by identifying vulnerable property, roads and infrastructure.” said Boreham.

By Keri McNamara, freelance science writer

Keri McNamara is a freelance writer with a PhD in Volcanology from the University of Bristol. She is on twitter @KeriAMcNamara and www.kerimcnamara.com.

Imaggeo on Mondays: The ash cloud of Eyjafjallajökull approaches

Imaggeo on Mondays: The ash cloud of Eyjafjallajökull approaches

This photo depicts the famous ash cloud of the Icelandic volcano Eyjafjallajökull, which disrupted air traffic in Europe and over the North Atlantic Ocean for several days in spring 2010. The picture was taken during the initial phase of the eruption south of the town of Kirjubæjarklaustur, at the end of a long field work day. Visibility inside the ash cloud was within only a few metres.

The eruption was preceded by years of seismic unrest and repeated magma intrusions. A first effusive fissure opened outside the ice shield of the volcano at the end of March 2010, followed by an explosive eruption in the main crater of the volcano in April 2010.

Iceland was well prepared for the eruption – the rest of the world obviously was not. The region around Eyjafjallajökull is sparsely populated, residents were prepared days before the eruption and the evacuation went smoothly. However, the grain size of the ejected volcanic ash was fine enough so that the unfavourable and unusual wind direction during these days transported the ash all the way to Europe and led to air space closures almost all over the continent.

By Martin Hensch, Nordic Volcanological Center, University of Iceland (now at Geological Survey of Baden-Württemberg, Germany)

Imaggeo is the EGU’s online open access geosciences image repository. All geoscientists (and others) can submit their photographs and videos to this repository and, since it is open access, these images can be used for free by scientists for their presentations or publications, by educators and the general public, and some images can even be used freely for commercial purposes. Photographers also retain full rights of use, as Imaggeo images are licensed and distributed by the EGU under a Creative Commons licence. Submit your photos at http://imaggeo.egu.eu/upload/.

Imaggeo on Mondays: In-tents Icelandic sunset

Imaggeo on Mondays: In-tents Icelandic sunset

This photograph was taken at the campsite near lake Mỳvatn during a field trip to Iceland. Every year a group of students from Wageningen University travels from the Netherlands to Iceland for a weeklong excursion as part of a course on catchment hydrology. The aim of the trip is to provide students with real life examples of the processes they learned during their lectures.

After a rainy morning that day, tents and equipment were packed away as quickly as possible in order to escape the wetness. The drive took the group from the campsite in Höfn, at the foot of the Vatnajökull glacier in southeastern Iceland, along the coastal highway up north towards Myvatn. Iceland is famous for its raw and beautiful nature, with waterfalls seemingly around every corner and the imposing presence of the glaciers and volcanos in the distance.

Upon our arrival at the campsite in the evening, people begrudgingly noticed that the tents were still wet from the morning rain. The campsite was situated at the bottom of a formidable hill, which provided stunning views over the lake and landscape. Not wanting to sleep in a damp tent, a few students picked up their tents, dismantled them, went up the hill and let the evening breeze do the rest, all amid the backdrop of a stunning sunset. The desire for dry covers even outweighed the very real danger of being eaten alive by masses of midges, a known pest and hazard in these parts.

When camping there is always things that can go wrong. But for places like Iceland it is the only way to truly appreciate and experience the country’s stunning beauty and wilderness. Gazing up at the northern lights from your sleeping bag is a once-in-a-lifetime experience. While waking up in the middle of the night and having to put on boots and jacket to run to the bathroom is vexing, you might be rewarded with views of the top of the glacier that has been shrouded in clouds all day, making it seem like Zeus himself is taking a peek down from Mount Olympus to see what is going on. Iceland has to be experienced, not from a cosy hotel bed, but from a tent put up in the evening and taken down the next day. As Albert Einstein once said: “Look deep into nature, and then you will understand everything better”. Even if that means hiking up a hill and holding your tent up into the wind to dry.

By Maria Warter, PhD student at Cardiff University



Imaggeo on Mondays: The breath of our Earth

Imaggeo on Mondays: The breath of our Earth

This picture was taken in the Myvatn geothermal area in southeast Iceland. Seeing the geothermal steam vent in this area while the temperature was -22 degrees Celsius is the best experience in Myvatn. The difference between Iceland’s cold ambient temperature and the released heat from inside the Earth is a really stunning event to see.

Iceland is situated in the middle of two tectonic plates (the Eurasian and North American plates) that, through their movement, have led to more than a hundred active and inactive volcanoes in this country. Due to the region’s high volcanic activity and shallow magma chambers, the temperature below Iceland’s surface is generally higher than that of continental areas without volcanoes. These conditions are responsible for the country’s high production of geothermal energy.

This heat can reach the surface in one of two ways. First, heat can naturally escape from the heart of Earth through cracks on the Earth’s surface itself. Second, geothermal powerplants can insert pipes far below the Earth’s surface to capture this heat.

Iceland is known for its geothermal spas, like the famous Blue Lagoon,  but additionally, Icelanders use geothermal energy as their main source of heating; in winter, almost 100 percent of the nation’s heating comes from geothermal energy. In the country’s capital Reykjavik, much of the city’s main roads are heated by this source, keeping the streets free from ice and snow. Geothermal energy also accounts for about 25 percent of the island’s electricity.

How is geothermal energy produced? As a heating source, geothermal power plants use a heat exchanger, a pipe that converts the hot water inside the earth into heat. It is then distributed within the steam pipe to residential areas. As an electricity source, power plants capture steam or hot water from geothermal areas to drive electricity generators. The machines convert the heat into electricity, which is then shared with Icelandic neighborhoods.

Because of its investment in a renewable energy source, Iceland is well known as a global leader in sustainability.

By Handriyanti Diah Puspitarini, University of Padova, Italy
