Geosciences Column: Scientists pinpoint where seawater could be leaking into Antarctic ice shelves

Geosciences Column: Scientists pinpoint where seawater could be leaking into Antarctic ice shelves

Over the last few decades, Antarctic ice shelves have been disintegrating at a rapid rate, likely due to warming atmospheric and ocean temperatures, according to scientists. New research reveals that one type of threat to ice shelf stability might be more widespread that previously thought.

A study recently published in EGU’s open access journal The Cryosphere identified several regions in Antarctica were liquid seawater could be leaking into vulnerable layers of an ice shelf.

Scientists have known for some time now that seawater can seep into an ice shelf’s firn layer, the region of compacted snow that is on its way to becoming ice. This seawater infiltration presents an issue to the ice shelf’s stability, since as the seawater spreads throughout the firn layer, the water can create fractures and help expand crevasses already present in the frozen material. Past research has shown that the presence of liquid brine from seawater within an ice shelf is correlated to increased fracturing and calving.

While ice shelf collapse doesn’t directly contribute to sea level rise, since the ice is already floating, stable ice shelves often push back on land-based ice sheets and glaciers, slowing down ice flow into the ocean. Past research has suggested that once an ice shelf collapses, the rate of ice flow from unsupported glaciers can greatly accelerate.

To better understand Antarctic ice shelves’ risk of collapse, the researchers involved with this new study sought to identify where ice shelf firn layers are vulnerable to seawater infiltration. Using Antarctic geometry data, they mapped out the potential ‘brine zones’ within the continent’s ice shelves. These are regions of the ice shelf where the firn layer is both below the sea level and permeable enough to let seawater percolate through.

The results of their analysis revealed that almost all ice shelves in Antarctica have spots where seawater can potentially leak through their layers, with about 10-40 percent of the continent’s total ice shelf area possibly at risk of infiltration.

Map of potential brine zones areas around Antarctica. Map shows areas where permeable firn lies below sea level (the brine zone), with the threshold for firn permeability defined as 750 kg m−3 (red), 800 kg m−3 (yellow) and 830 kg m−3 (blue) calculated using Bedmap2 surface elevation. Bar charts show the mean percentage area of selected ice shelves covered by the brine zone. (Credit: S. Cook et al. 2018)

The researchers compared their estimated points to a map of previously confirmed brine zones, observed through ice cores or radar surveys. After reviewing these records, they identified only one record of brine presence that hadn’t been highlighted by their developed model.

The study found many areas in Antarctica where seawater infiltration could be possible, but has not been previously observed. The findings suggest that this firn layer vulnerability to seawater might be more widespread than previously believed.

The researchers suggest that the most likely new regions where brine from seawater may be present includes the Abbot Ice Shelf, Nickerson Ice Shelf, Sulzberger Ice Shelf, Rennick Ice Shelf, and slower-moving areas of Shackleton Ice Shelf. The regions all contain large swathes of permeable firn below sea level while also subject to relatively warm air temperatures and low flow speeds, the ideal conditions for maintaining liquid brine.

The study points out that there are still many uncertainties in this research, considering the unknowns still present in the data used for mapping and the factors that may influence seawater infiltration. For example, some areas that have large predicted brine zones have an unusually think layer of firn from heavy snowfall. This is the case for the Edward VIII Bay in eastern Antarctica. “Our results indicate the total ice shelf area where permeable firn lies below sea level, but this does not necessarily imply that the firn contains brine,” the authors of the study noted in their article.

Given their findings, the researchers involved recommend that this potentially widespread influence on ice shelves should be further examined and assessed by future studies.

By Olivia Trani, EGU Communications Officer

References

Cook, S., Galton-Fenzi, B. K., Ligtenberg, S. R. M. and Coleman, R.: Brief communication: widespread potential for seawater infiltration on Antarctic ice shelves, The Cryosphere, 12(12), 3853–3859, doi:10.5194/tc-12-3853-2018, 2018.

Hoegh-Guldberg, O., D. Jacob, M. Taylor, M. Bindi, S. Brown, I. Camilloni, A. Diedhiou, R. Djalante, K.L. Ebi, F. Engelbrecht, J.Guiot, Y. Hijioka, S. Mehrotra, A. Payne, S.I. Seneviratne, A. Thomas, R. Warren, and G. Zhou, 2018: Impacts of 1.5ºC Global Warming on Natural and Human Systems. In: Global Warming of 1.5°C. An IPCC Special Report on the impacts of global warming of 1.5°C above pre-industrial levels and related global greenhouse gas emission pathways, in the context of strengthening the global response to the threat of climate change, sustainable development, and efforts to eradicate poverty [Masson-Delmotte, V., P. Zhai, H.-O. Pörtner, D. Roberts, J. Skea, P.R. Shukla, A. Pirani, W. Moufouma-Okia, C. Péan, R. Pidcock, S. Connors, J.B.R. Matthews, Y. Chen, X. Zhou, M.I.Gomis, E. Lonnoy, T.Maycock, M.Tignor, and T. Waterfield (eds.)]. In Press

Scambos, T. A.: Glacier acceleration and thinning after ice shelf collapse in the Larsen B embayment, Antarctica, Geophysical Research Letters, 31(18), doi:10.1029/2004gl020670, 2004.

Scambos, T., Fricker, H. A., Liu, C.-C., Bohlander, J., Fastook, J., Sargent, A., Massom, R. and Wu, A.-M.: Ice shelf disintegration by plate bending and hydro-fracture: Satellite observations and model results of the 2008 Wilkins ice shelf break-ups, Earth and Planetary Science Letters, 280(1–4), 51–60, doi:10.1016/j.epsl.2008.12.027, 2009.

State of the Cryosphere: Ice Shelves. National Snow & Ice Data Center

Imaggeo on Mondays: An iceberg-sized issue

Imaggeo on Mondays: An iceberg-sized issue

This was taken during a study, undertaken by me and my colleagues, on the sea ice of McMurdo Sound, Antarctica. We designed the project to document how supercooled water carrying suspended ice crystals flows along its pathway towards the open ocean. Ultimately, this work aims to assess the Ross Ice Shelf’s contribution of local melt to the long-term trend of increased sea ice cover around Antarctica – a signal which has been dominated by expansion in the Ross Sea.

However, over the winter prior to the field season an iceberg, 12 kilometres long and 1 kilometre wide that had calved from the Ross Ice Shelf, grounded itself across the middle of our intended study region. This created a significant constriction to the flow, as the iceberg forced the approximately 30 km-wide plume to squeeze into half of that space.

We quickly modified the objectives for the field season to take advantage of this, adding an element focusing on the fluid dynamics of accelerated large-scale flow around the tip of the iceberg, and another on the thermodynamics of the supercooled plume interacting with a deep wall of ice. These adjustments to our study required drilling several holes through the sea ice along lines that approached the iceberg from two different directions to collect the necessary oceanographic data.

The iceberg towers about 40 m above the frozen sea surface, with our field support team providing scale as they scope a route of safe approach. However, hidden from sight by the sea ice, the iceberg stretches a further 170 m below the surface to the point where it is grounded on the seafloor.

Conducting field science in Antarctica requires being able to adapt to a dynamic environment. In this case, our flexibility was rewarded with a unique data set – essentially a laboratory study in fluid mechanics on a real-world scale.

By Natalie Robinson, New Zealand National Institute for Water and Atmospheric Research (NIWA)

If you pre-register for the 2019 General Assembly (Vienna, 07–12 April), you can take part in our annual photo competition! From 15 January until 15 February, every participant pre-registered for the General Assembly can submit up three original photos and one moving image related to the Earth, planetary, and space sciences in competition for free registration to next year’s General Assembly!  These can include fantastic field photos, a stunning shot of your favourite thin section, what you’ve captured out on holiday or under the electron microscope – if it’s geoscientific, it fits the bill. Find out more about how to take part at http://imaggeo.egu.eu/photo-contest/information/.

Imaggeo is the EGU’s online open access geosciences image repository. All geoscientists (and others) can submit their photographs and videos to this repository and, since it is open access, these images can be used for free by scientists for their presentations or publications, by educators and the general public, and some images can even be used freely for commercial purposes. Photographers also retain full rights of use, as Imaggeo images are licensed and distributed by the EGU under a Creative Commons licence. Submit your photos at http://imaggeo.egu.eu/upload/.

Imaggeo on Mondays: Crowned elephant seals do citizen science

Imaggeo on Mondays: Crowned elephant seals do citizen science

In the Southern Ocean and North Pacific lives a peculiar type of elephant seal. This group acts like any other marine mammal; they dive deep into the ocean, chow down on fish, and sunbathe on the beach. However, they do all this with scientific instruments attached to their heads. While the seals carry out their usual activities, the devices collect important oceanographic data that help scientists better understand our marine environment.

The practice of tagging elephant seals to obtain data started in 2004, and today equipped seals are the largest contributors of temperature and salinity profiles below of the 60th parallel south. You can find all sorts of data that has been collected by instrumented sea creatures through the Marine Mammals Exploring the Oceans Pole to Pole database online.

The female elephant seal, pictured here at Point Suzanne on the eastern end of the Kerguelen Islands in the Southern Ocean, is a member of this unusual headgear-wearing cohort. This particular seal had been roaming the sea for several months with the device (also known as a miniature Conductivity-Temperature-Depth sensor) on her head. As the seal dove hundreds of metres below the sea surface, the instrument captured the vertical profile of the area, recording the ocean’s temperature and salinity, as well as chlorophyll a fluorescence and concentrations. When the seal resurfaced, the sensor sent the data it had accrued to scientists by satellite.

Etienne Pauthenet, a PhD student at Stockholm University who was involved in a seal tagging campaign, had a chance to snap this photo before tranquilising the seal and retrieving the tag.

Using elephant seals and other marine mammals to collect data gives scientists the opportunity to analyse remote regions of the ocean that aren’t very accessible by vehicles. Studying these parts of the world are important for gaining insight on how oceans and their inhabitants are responding to climate change, for example. With the help of data-gathering elephant seals, researchers are able to amass in situ measurements from regions that previously had been hard to reach, apply this data to oceanographic models, and make predictions on ocean climate processes.

While gathering data via elephant seals are crucial to oceanographic research, Pauthenet explains that the practice is sometimes quite difficult. “It can be complicated to find back the seal, because of the Argo satellite signal precision. The quality of the signal depends on the position of the seal, if she is lying on her back for example, or if she is still in the water.”

While on the research campaign, Pauthenet and his colleagues were stationed at a small cabin on the shore of Point Suzanne and they walked the shore every day in search of the seal, relying on location points transmitted from a VHF radio. After seven days they finally located her and removed her valuable crown. The seal was then free to go about her business, having given her contribution to the hundreds of thousands of vertical profiles collected by marine mammal citizen scientists.

by Olivia Trani, EGU Communications Officer
Imaggeo is the EGU’s online open access geosciences image repository. All geoscientists (and others) can submit their photographs and videos to this repository and, since it is open access, these images can be used for free by scientists for their presentations or publications, by educators and the general public, and some images can even be used freely for commercial purposes. Photographers also retain full rights of use, as Imaggeo images are licensed and distributed by the EGU under a Creative Commons licence. Submit your photos at http://imaggeo.egu.eu/upload/.

Imaggeo on Mondays: Antarctic winds make honeycomb ice

Imaggeo on Mondays: Antarctic winds make honeycomb ice

These delicate ice structures may look like frozen honeycombs from another world, but the crystalline patterns can be found 80 degrees south, in Antarctica, where they are shaped by the white continent’s windy conditions.

In Western Antarctica is a 9-kilometre line of rocky ridges, called Patriot Hills. Often cold wind furiously descends from the hills across Horseshoe Valley glacier, sculpting doily-like designs into the surface layer. “The wind exploits weaknesses in the ice structure, picking out the boundaries between individual ice crystals, leading to the formation of a honeycomb pattern,” said Helen Millman, a PhD student at the University of New South Wales Climate Change Research Centre, who captured this photograph at Patriot Hills.

Besides creating decorations out of Antarctica’s ice, the region’s intense winds, known as katabatic winds, also cause sublimation, in which the ice on the glacier’s surface turns directly into water vapour. This phenomenon creates a snow-free zone that experiences a net loss in frozen mass, also known as ablation; it also gives the ice a slightly blue hue and ”small, smooth waves that resemble the ocean in a light breeze, despite the intensity of the katabatic winds,” Millman added.

A stretch of blue ice in Antarctica. Credit: Helen Millman

“Since older ice rises as the surface layers are ablated, the ice at the surface of blue ice areas may be hundreds of thousands, or even millions of years old,” said Millman. This allows for some pretty interesting geological artifacts to reach the glacier’s surface, such as meteorites. “This conveyor belt of old ice rising to the surface means that high concentrations of meteorites can be found in blue ice areas.” Scientists can study these ancient Antarctic meteorites to learn more about the formation and evolution of our solar system. The Antarctic Search for Meteorites program for instance has collected more than 21,000 meteorites since 1976, and are on the hunt for more.
