Is it an earthquake, a nuclear test or a hurricane? How seismometers help us understand the world we live in

Is it an earthquake, a nuclear test or a hurricane? How seismometers help us understand the world we live in

Although traditionally used to study earthquakes, like today’s M 8.1 in Mexico,  seismometers have now become so sophisticated they are able to detect the slightest ground movements; whether they come from deep within the bowels of the planet or are triggered by events at the surface. But how, exactly, do earthquake scientists decipher the signals picked up by seismometers across the world? And more importantly, how do they know whether they are caused by an earthquake, nuclear test or a hurricane?

To find out we asked Neil Wilkins (a PhD student at the University of Bristol) and Stephen Hicks (a seismologist at the University of Southampton) to share some insights with our readers.


Seismometers are highly sensitive and they are able to detect a magnitude 5 earthquake occurring on the other side of the planet. Also, most seismic monitoring stations have sensors located within a couple of meters of the ground surface, so they can be fairly susceptible to vibrations at the surface. Seismologists can “spy” on any noise source, from cows moving in a nearby field to passing trucks and trains.

A nuclear test

On Sunday the 3rd of September, North Korea issued a statement announcing it had successfully tested an underground hydrogen bomb. The blast was confirmed by seismometers across the globe. The U.S.  Geological Survey registered a 6.3 magnitude tremor, located at the Punggye-ri underground test site, in the northwest of the country. South Korea’s Meteorological Administration’s earthquake and volcano center also detected what is thought to be North Korea’s strongest test to date.

However they occur, explosions produce ground vibrations capable of being detected by seismic sensors. Mining and quarry blasts appear frequently at nearby seismic monitoring stations. In the case of nuclear explosions, the vibrations can be so large that the seismic waves they produce can be picked up all over the world, as in the case of this latest test.

It was realised quite early in the development of nuclear weapons that seismology could be used to detect such tests. In fact, the need to have reliable seismic data for monitoring underground nuclear explosions led in part to the development of the Worldwide Standardized Seismograph Network in the 1960s, the first of its kind.

Today, more than 150 seismic stations are operating as part of the International Monitoring System (IMS) to detect nuclear tests in breach of the Comprehensive Test-Ban Treaty (CTBT), which opened for signatures in 1996. The IMS also incorporates other technologies, including infrasound, hydroacoustics and radionuclide monitoring.

The key to determining whether a seismic signal is from an explosion or an earthquake lies in the nature of the waves that are present. There are three kinds of seismic wave seismologists can detect. The fastest, called Primary (P) waves, cause ground vibrations in the same direction that they travel, similar to sound waves in the air. Secondary (S) waves cause shaking in a perpendicular direction. Both P and S waves travel deep through the Earth and are known collectively as body waves. In contrast, the third type of seismic waves are known as surface waves, because they are trapped close to the surface of the Earth. In an earthquake, it is normally surface waves that cause the most ground shaking.

In an explosion, most of the seismic energy is released outwards as the explosive material rapidly expands. This means that the largest signal in the seismogram comes as P waves. Explosions therefore have a distinctive shape in the seismic data when compared with an earthquake, where we expect S and surface waves to have higher amplitude.

Forensic seismologists can therefore make measurements of the seismic data to determine whether there was an explosion. An extra indication that a nuclear test occurred can also be revealed by measuring the depth of the source of the waves, as it would not be possible to place a nuclear device deeper than around 10 km below the surface.

Yet while seismic data can tell us that there has been an explosion, there is nothing that can directly identify that explosion as being nuclear. Instead, the IMS relies on the detection of radioactive gases that can leak from the test site for final confirmation of what kind of bomb was used.

The figure shows (at the bottom) the seismic recording of the latest test in North Korea made at NORSAR’s station in Hedmark, Norway. The five upper traces show recordings at the same station for the five preceding tests, conducted by North Korea in 2006, 2009, 2013 and 2016 (two explosions in 2016). The 2017 test, is as can be seen from this figure, clearly the strongest so far. Credit: NORSAR.

When North Korea conducted a nuclear test in 2013, radioactive xenon was detected 55 days later, but this is not always possible. Any detection of such gases depends on whether or not a leak occurs in the first place, and how the gases are transported in the atmosphere.

Additionally, the seismic data cannot indicate the size of the nuclear device or whether it could be attached to a ballistic missile, as the North Korean government claims.

What seismology can give us is an idea of the size of the explosion by measuring the seismic magnitude. This is not straightforward, and depends on knowledge of exactly how deep the bomb was buried and the nature of the rock lying over the test site. However, by comparing the magnitude of this latest test with those from the previous five tests conducted in North Korea, we can see that this is a much larger explosion.

The Norwegian seismic observatory NORSAR has estimated a blast equivalent to 120 kilotons of TNT, six times larger than the atomic bomb dropped on Nagasaki in 1945, and consistent with the expected yield range of a hydrogen bomb.

Hurriquakes?

Nuclear tests are not the only hazard keeping our minds busy in the past few weeks. In the Atlantic, Hurricanes Harvey, Irma and Katia have wreaked havoc in the southern U.S.A, Mexico and the Caribbean.

Hurricanes in the Atlantic can occur at any time between June and November. According to hurricane experts, we are at the peak of the season. It is not uncommon for storms to form in rapid succession between August, September and October.

The National Hurricane Centre (NHC) is the de facto regional authority for producing hurricane forecasts and issuing alerts in the Atlantic and eastern Pacific. For their forecasts, meteorologists use a combination of on the ground weather sensors (e.g. wind, pressure, Doppler radar) and satellite data.

As hurricane Irma tore its way across the Atlantic, gaining strength and approaching the Caribbean island of Guadeloupe, local seismometers detected its signature, sending the global press into a frenzy. It may come as a slight surprise to some people that storms and hurricanes also show on seismometers.

However, a seismometer detecting an approaching hurricane is not actually that astonishing. There is no evidence to suggest that hurricanes directly cause earthquakes, so what signals can we detect from a hurricane? Rather than “signals”, seismologists tend to refer to this kind of seismic energy as “noise” as it thwarts our ability to see what we’re normally looking out for – earthquakes.

The seismic noise from a storm doesn’t look like distinct “pings” that we would see with an earthquake. What we see are fairly low-pitched “hums” that gradually get louder in the days and hours preceding the arrival of a storm. As the storm gets closer to the sensor, these hums turn into slightly higher-pitched “rustling”. This seismic energy then wanes as the hurricane drifts away. We saw this effect clearly for Hurricane Irma with recordings from a seismometer on the island of Guadeloupe.

What causes these hums and rustles? If you look at the frequency content of seismic data from any monitoring station around the globe, noise levels light up at frequencies of ~0.2 Hz (5 s period). We call these hums “microseism”. Microseism is caused by persistent seismic waves unrelated to earthquakes, and it occurs over huge areas of the planet.  One of the strongest sources of microseism is caused by ocean waves and swell. During a hurricane, swell increases and ocean waves become more energetic, eventually crashing into coastlines, transferring seismic energy into the ground. This effect is more obvious on islands as they are surrounded by water.

As the hurricane gets closer to the island, wind speeds dramatically increase and may dwarf the noise level of the longer period microseism. Wind rattles trees, telegraph poles, and the surface itself, transferring seismic energy into the ground and moving the sensitive mass inside the seismometer. This effect causes higher-pitched “rustles” as the centre of the storm approaches. Gusts of wind can also generate pressure changes inside the seismometer installation and within the seismometer itself, generating longer period fluctuations.

During Hurricane Irma, a seismic monitoring station located in the Dutch territory of St. Maarten clearly recorded the approach of the storm, leading to an intense crescendo as the eyewall crossed the area. As the centre of the eye passed over, the seismometer seems to have recorded a slightly lower noise level. This observation could be due to the calmer conditions and lower pressure within the eye. The station went down shortly after, probably from a power outage or loss in telemetry which provides the data in real-time.

Seismometers measuring storms is not a new observation. Recently, Hurricane Harvey shook up seismometers located in southern Texas. Even in the UK, the approach of winter storms across the Atlantic causes much higher levels of microseism.

It would be difficult to use seismometer recordings to help forecast a hurricane – the recordings really depend on how close the sensor is to the coast and how exposed the site is to wind. In the event of outside surface wind and pressure sensors being damaged by the storm, protected seismometers below the ground could possibly prove useful in delineating the rough location of the hurricane eye, assuming they maintain power and keep sending real-time data.

At least several seismic monitoring stations in the northern Antilles region were put out of action by the effects of the Hurricane. Given the total devastation on some islands, it is likely that it will take at least several months to bring these stations back online. The Lesser Antilles are a very tectonically active and complex part of Earth; bringing these sensors back into operation will be crucial to earthquake and volcano hazard monitoring in the region.

By Neil Wilkins (PhD student at the University of Bristol) and Steven Hicks (a seismologist at the University of Southampton)

References and further reading

GeoSciences Column: Can seismic signals help understand landslides and rockfalls?

NORSAR Press Release: Large nuclear test in North Korea on 3 September 2017

The Comprehensive Nuclear-Test-Ban Organization Press Release: CTBTO Executive Secretary Lassina Zerbo on the unusual seismic event detected in the Democratic People’s Republic of Korea

First Harvey, Then Irma and Jose. Why? It’s the Season (The New York Times)

NOAA  National Hurricane Center

IRIS education and outreach series: How does a seismometer work?

Imaggeo on Mondays: Sediments make the colour

Imaggeo on Mondays: Sediments make the colour

Earth is spectacularly beautiful, especially when seen from a bird’s eye view. This image, of a sweeping pattern made by a river in Iceland is testimony to it.

The picture shows river Leirá which drains sediment-loaded glacial water from the Myrdalsjökull glacier in Iceland. Myrdalsjökull glacier covers Katla, one of Iceland’s most active and ice-covered volcanoes.

A high sediment load (the suspended particles which are transported in river water) is typical for these glacial rivers and is visible as the fast-flowing glacial river (on the right of this image) appears light brown in colour. The sediment is gradually lost in the labyrinth of small lakes and narrow, crooked connections between lakes as can be seen as a gradual change in colour to dark blue.

The sediment load, height of the water  and chemistry of this and other glacial rivers are measured partly in real-time by the Icelandic Meteorological Office. This is done for research purposes and in order to detect floods from subglacial lakes that travel up to several tens of kilometers beneath the glacier before they reach a glacial river.

These glacial outburst floods do not only threaten people, livestock and property, but also infrastructure such as Route 1, a circular, national road which runs around the island. They occur regularly due to volcanic activity or localized geothermal melting on the volcano, creating a need for an effective early-warning system.

Advances in the last years include the usage of GPS instruments on top of a subglacial lake and the flood path in order to increase the early-warning for these floods. In 2015, the GPS network, gave scientists on duty at the Icelandic Meteorological Office 3.5 days of warning before one of the largest floods from western Vatnajökull emerged from beneath the ice.

The peak discharge exceeded 2000 m3/s,  which is comparable to an increase in discharge from that of the Thames to that of the Rhine.  This flood was also pioneeringly monitored with clusters of seismometers, so called arrays (from University College Dublin & Dublin Institute for Advanced Studies, Ireland), that enabled an early-warning of at least 20 hours and allowed to track the flood front merely using the ground vibrations it excited. The flood propagated under the glacier at a speed of around 2 km/h; so assuming you can keep up the speed over nearly a day you can escape the flood by walking while it is moving beneath the glacier.

Related publications about the tracking of these subglacial floods will emerge in the published literature soon (real time update available at www.evapseibl.wordpress.com).

By Eva Eibl, researcher at the Dublin Institute for Advanced Studies.

Thanks go to www.volcanoheli.is who organised this trip.

Imaggeo is the EGU’s online open access geosciences image repository. All geoscientists (and others) can submit their photographs and videos to this repository and, since it is open access, these images can be used for free by scientists for their presentations or publications, by educators and the general public, and some images can even be used freely for commercial purposes. Photographers also retain full rights of use, as Imaggeo images are licensed and distributed by the EGU under a Creative Commons licence. Submit your photos at http://imaggeo.egu.eu/upload/.



GeoSciences Column: Can seismic signals help understand landslides and rockfalls?

GeoSciences Column: Can seismic signals help understand landslides and rockfalls?

From the top of a small gully in the French Alps, a 472 kg block is launched into the chasm. Every detail of it’s trajectory down the slope is scrutinised by two cameras and a network of seismometers. They zealously record every bounce, scrape and tumble – precious data in the quest to better understand landslides.

What makes landslides tick?

In 2016, fatalities caused by landslides tipped 2,250 people. The United States Geological Survey (USGS) estimates that between 25 and 50 people are killed, annually, by landslides in the United States alone. Quantifying the economic losses caused by landslides is no easy task, but the costs are known to be of economic significance.

It is paramount that the mechanisms which govern landslides are better understood in hopes that the knowledge will lead to improved risk management in the future.

But landslides and rockfalls are rarely observed in real-time. Deciphering an event, when all you have left behind is a pile of debris, is no easy task. The next best thing (if not better than!) to witnessing a landslide (from a safe distance) is having a permanent record of its movement as it travels down a slope.

Although traditionally used to study earthquakes, seismometers have now become so sophisticated they are able to detect the slightest ground movements; whether they come from deep within the bowels of the planet or are triggered by events at the surface. For some year’s now they have been an invaluable tool in detecting mass movements (an all-encompassing term for the movement of bed rock, rock debris, soil, or mud down a slope) across the globe.

More recently, processing recorded seismic signals triggered by large catastrophic events has not only allowed to identify when and where they occurred, but also their force, how quickly they travel, gain speed and their direction of movement.

This approach gives only a limited amount of data for scientists to work with. After all, large, catastrophic, mass movements represent only a fraction of the landslide and rockfall events that occur worldwide. To gain a fuller understanding of landslide processes, information about the smaller events is needed too.

So, what if scientists could use a seismic signal which is generated by all mass movements, independent of their size?

The high-frequency seismic signal

A high-frequency seismic signal is generated as the individual particles, which combined make up a landslide or rockfall, bounce and tumble against the underlying layer of rock. Would it be possible to, retrospectively, find out information about the size and speed at which individual particles traveled from this seismic signal alone?

This very question is what took a team of scientists up into the valleys of the French Alps.

At a place where erosion carves gullies into lime-rich muds, the researchers set-up two video cameras and network of seismometers. They then launched a total of 28 blocks, of weights ranging from 76 to 472 kg, down a 200 m long gully and used the data acquired to reconstruct the precise trajectory of each block.

The impacts of each block on the underlying geology, as seen on camera, were plotted on a 3D representation of the terrain’s surface. From the time of impact, block flight time and trajectory, the team were able to find out the velocity at which the blocks travelled and the energy they carried.

View from (a) the first and (b) the second video cameras deployed at the bottom of the slope. The ground control points are indicated by blue points. (c) Trajectory reconstruction for block 4 on the DEM, built from lidar acquisition, superimposed on an orthophoto
of the Rioux-Bourdoux slopes. Each point indicates the position of an impact and the colour gradient represents the chronology of these impacts (blue for the first impact and red for the last one). K2 is a three-component short-period seismometer and K1, K3 and K3 are vertical-only seismometers. CMG1 is a broad-band seismometer. From Hibert, C. et al., 2017. (Click to enlarge)

As each block impacted the ground, it generated a high-frequency seismic signal, which was recorded by the seismometers. The signals were processed to see if information about the (now known) properties of the blocks could be recovered.

Following a detailed analysis, the team of scientists, who recently published their results in the EGU’s open access journal Earth Surface Dynamics, found a correlation between the amplitude (the height of the wave from it’s resting position), as well as the energy of the seismic signals and the mass and velocities of the blocks before impact. This suggests that indeed, these high-frequency seismic signal can be used to find out details about rockfall and landslide dynamics.

But much work is left to be done.

There is no doubt that the type of substrate on which the particles/blocks bounce upon play a large part in governing the dynamics of mass movements. In the case of the French Alps experiment, the underlying geology of lime-rich muds was very soft and absorbed some of the energy of the impacts. Other experiments (which didn’t use single blocks), performed in hard volcanic and metamorphic rocks, found energy absorption was lessened. To really get to the bottom of how much of a role the substrate plays, single-block, controlled release experiments, like the one described in the paper, should be performed on a variety of rock types.

At the same time, while this experiment certainly highlights a link between seismic signals and individual blocks, rockfalls and landslides are made up of hundreds of thousands of particles, all of which interact with one another as they cascade down a slope. How do these complex interactions influence the seismic signals?

By Laura Roberts Artal, EGU Communications Officer

References and resources:

Hibert, C., Malet, J.-P., Bourrier, F., Provost, F., Berger, F., Bornemann, P., Tardif, P., and Mermin, E.: Single-block rockfall dynamics inferred from seismic signal analysis, Earth Surf. Dynam., 5, 283-292, doi:10.5194/esurf-5-283-2017, 2017.

USGS FAQs: How many deaths result from landslides each year?

The human cost of landslides in 2016 by David Petley, published, 30 January 2017 in The Landslide Blog, AGU Blogosphere.

[Paywalled] Klose M., Highland L., Damm B., Terhorst B.: Industrialized Countries: Challenges, Concepts, and Case Study. In: Sassa K., Canuti P., Yin Y. (eds) Landslide Science for a Safer Geoenvironment. Springer, Cham, (2014)



GeoTalk: Beatriz Gaite on why videos are a great tool for communicating your research to a broad audience

GeoTalk: Beatriz Gaite on why videos are a great tool for communicating your research to a broad audience

If you’ve not heard about our Communicate Your Science Video Competition before it gives early career scientists the chance to produce a video up-to-three-minutes long to share their research with the general public. The winning entry receives a free registration to the General Assembly the following year.

In this GeoTalk interview, Laura Roberts talks to Beatriz Gaite an early career scientist whose video on how recycling the noisy part of recordings made by seismometers can tells us important information about the Earth’s interior structure was voted as the winning entry of the 2016 Communicate Your Science Video Competition. Read on to hear about their top tips for filming a science video and what inspired them to use video to communicate their science in the first place.

Before we get started, could you introduce yourself and tell our readers a little more about your research?

I am a seismologist mainly studying the Earth structure. I did my PhD on Mexico and its vicinity using a novel approach developed in the last decade. Before, seismologists used to study earthquake signals to infer the inner structure, but now we can also study seismic ambient noise, which is everything on a seismic record… except the earthquake signals! This means we now analyse what  used to be thrown away, once considered useless. In this sense, it is like recycling. This has revolutionised the field and opened multiple applications, not only for imaging the Earth interior, but also for monitoring landslides, volcanoes or climate change effects.

Some of our readers may yet not be familiar with the competition, can you tell us a little more about it and what made you decide to take part in the competition?

Yes, the EGU video competition consists on explaining your research to a general audience through a three minute video. Once ready, you submit your video to EGU and disseminate it as much as possible to get people to vote for it . I decided to take part  because I was fascinated with the bunch of applications developed from seismic ambient noise and aware of the importance of communicating science to society. This cocktail of thoughts inspired me to create the video.

Watch Beatriz’s winning film, Subtle Whisper of the Earth

Had you filmed any science videos prior to producing ‘Subtle Whisper of the Earth’?

No, never. Only as a teenager I recorded some short, home-made videos for outdoor activities, but nothing related with science. However, in the production of Shubtle Whisper of the Earth I was helped by two professionals: Jordi Cortés, the journalist in charge of the communication at the Institute of Earth Sciences Jaume Almera, ICTJA-CSIC, who filmed and edited the video, and Daniel García (@rocambloguesco), an Earth Sciences communicator who helped me with the script.

What inspired you to make a film about your research and submit the entry to the competition?

Since I finished my PhD I was thinking about making a documentary to show how seismic ambient noise was such a big evolution for seismology. Indeed, I already had some script ideas bubbling in my mind. Then, I found out  about the competition through the recently created communication department of my center and, after thinking about it I went for it. I thought it [the video competition} was a great opportunity to make my ideas real.

We can’t go into too much detail here, but how did you go about collecting the footage and turning it into a film?

First, I adapted my original ideas to the length of the video competition specifications. After several iterations, I got the main idea. In parallel, I thought on the story: I needed something common to people, like recycling. I made a script, then Daniel helped me to simplify it from the research realm to society, and I organised it in sequences, duration and film resources. All these steps were the most time-consuming part. Jordi and I organized the “field work” dividing the filming on indoor and outdoor. Since we organized the sequence planning in advance, it took us only one morning shooting indoors and one afternoon outdoors. Jordi’s experience behind the camera and in  production helped a lot to get the final video, but we only used user-level material and software for producing and editing.

What’s your top tip for aspiring science filmmakers?

Have a clear idea of the message you want to communicate. Also, you need a story to catch the attention of the audience. Once you have the idea and the story, the next step, how to visually express them, comes easily.

Beatriz preparing materials to be used in the making of her film. Credit: Jordi Cortés

Which part of the filming process did you enjoy the most?

I enjoyed the whole process, but especially two parts: first, the beginning of the creative process, thinking what, why, and how I wanted to communicate the story, imagining the screenshots in my mind. And second, shooting with Jordi was really fun, I enjoyed it a lot, it was like a game.

Would you recommend filmmaking as a way for scientist to reach out to a broad audience?

Sure! When I started I did not think that the video would reach as many people as it did. I was really happy when some friends told me ‘now we know what you do’. Even some colleagues told me that now they understood pretty well what we get from the seismic ambient noise. It is worth it. A short video is a good way to reach a broad audience globally. Being short, specific and visual are good ingredients to grab attention.

Would you recommend others taking part in the Communicate your Science Video Competition?

Yes, of course. It is an enjoyable exercise to communicate your research. The hardest part of the competition is the self-promotion to get votes, but that’s a different story 😉

Has this interview inspired you to go forth and produce a science video? The Communicate Your Science Video Competition is currently open for submissions.

If you are pre-registered to attend the General Assembly in April, go ahead and produce a video with scenes of you out in the field, or at the lab bench showing how to work out water chemistry; entries can also include cartoons, animations (including stop motion), or music videos, – you name it! To submit your video simply email it to Laura Roberts (networking@egu.eu) by 26 February 2017.

For more information about the competition take a look at this blog post. For inspiration, why not take a look at the finalist videos from the 2015 and 2016 editions? For more tips and tricks on how to make a video to communicate your research read an interview with vlogger extraordinaire Simon Clark. We also spoke to Zakaria Ghazoui, winner of the 2015 video competition to as his thoughts on how to make a great video.
