Imaggeo on Mondays: Isolated atoll

Imaggeo on Mondays: Isolated atoll

Covering a total area of 298 km², the idylic natural atolls and reefs of the Maldives stretch across the Indian Ocean. The tropical nation is famous for it’s crystal clear waters and picture perfect white sand beaches, but how did the 26 ring-shaped atolls and over 1000 coral islands form?

Coral reefs commonly form immediately around an island, creating a fringe which projects seawards from the shore. If the island is of volcaninc origin and slowly subsides below sea level, while the coral continues to grow growing outwards and upwards, an atoll is formed. They are usually roughly circular in shape and have a central lagoon. If the coral reef grows high enough, it will emerge from the sea waters and start to form a  tiny island.

“I took this photo while flying over the Maldives, south of Malè, from a small seaplane,” describes Favaro, who took this stunning aerial image of an atoll above the Indian Ocean.

Pictured, goes on to explain Favaro,

“[is] part of the ring-shaped coral reef bounding the atoll. On the right side of the image there is the lagoon and on the left side the open ocean. The coral reef is interrupted twice by ‘Kandu’ (water passages in Dhivehi [the language spoken in the Maldives]), which are the places where water flows in and out of the atoll when the tides changes”.

Two small harbours and antennas suggest the two small islands are occupied by local people, not by a resort or hotels.

“What always strikes me is how they can live so isolated, in a place which doesn’t offer basic resources, such as drinkable water,” says Favaro.

Fresh water is scarce in this archipelago nation. Rainwater harvesting is unreliable; poor rainfall means depleted collection tanks and groundwater tables. The problem is being exacerbated by climate change which is altering the monsoon cycle and rainfall patters over the Indian Ocean. As a result, the country relies heavily on desalination plants (and imported bottled water) to sustain the nation and the 1 million tourists who visit annually.

This animation shows the dynamic process of how a coral atoll forms. Corals (represented in tan and purple) begin to settle and grow around an oceanic island forming a fringing reef. It can take as long as 10,000 years for a fringing reef to form. Over the next 100,000 years, if conditions are favorable, the reef will continue to expand. As the reef expands, the interior island usually begins to subside and the fringing reef turns into a barrier reef. When the island completely subsides beneath the water leaving a ring of growing coral with an open lagoon in its center, it is called an atoll. The process of atoll formation may take as long as 30,000,000 years to occur. Caption and figure credit: National Oceanographic and Atmospheric Administration (NOAA).

References and further reading

How Do Coral Reefs Form? An educational resource by NOAA

Amazing atolls of the Maldives – a feature on NASA’s Earth Observatory.



Imaggeo is the EGU’s online open access geosciences image repository. All geoscientists (and others) can submit their photographs and videos to this repository and, since it is open access, these images can be used for free by scientists for their presentations or publications, by educators and the general public, and some images can even be used freely for commercial purposes. Photographers also retain full rights of use, as Imaggeo images are licensed and distributed by the EGU under a Creative Commons licence. Submit your photos at http://imaggeo.egu.eu/upload/.



GeoSciences Column: Catch of the day – what seabirds can tell us about the marine environment

GeoSciences Column: Catch of the day – what seabirds can tell us about the marine environment

Off the coast of Germany, a male northern gannet (for ease, we’ll call him Pete) soars above the cold waters of the North Sea. He’s on the hunt for a shoal of fish. Some 40km due south east, Pete’s mate and chick await, patiently, for him to return to the nest with a belly full of food.

Glints of silver just below the waves; the fish have arrived.

Pete readies himself.

Body rigid, wings tucked in close – but not so close that he can’t steer himself – he dives toward the water at a break-neck speed, hitting almost 100 km per hour. Just as he is about to hit the water, Pete folds his wings, tight, against his body. He pierces the water; straight as an arrow, fast as a bullet, and makes his catch.

The first of the day.

He’ll continue fishing for the next 8 to 10 hours.

As he does so, a tiny logger weighing no more than 48 g, will continually track Pete’s position and with every dive, the temperature of the sea water.

Why equip birds with sensors?

The physical properties of the oceans, such as water temperature, play an important role in determining where organisms are found in the vastness of the oceans. Life tends to concentrate in regions where there are temperature changes, be that as waters get deeper or across large horizontal distances.

Sea surface temperatures also reveal vital information about the global climate system, as they help scientists understand how the oceans are connected to the atmosphere. The data are used in weather forecasts and simulations of how the Earth’s atmosphere changes over time.

By mounting light-weight loggers on diving mammals (it needn’t be only birds, seals and penguins are good candidates too), scientists can learn a lot from the animal’s behaviour, while at the same time collecting data about the physical properties of the oceans.

That is why a German research team, led by Stefan Garthe of the Research & Technology Centre (FTZ) at Kiel University, has been tagging and monitoring the behaviour of a colony of northern gannets breeding on the German island of Heligoland. As a top marine predator, changes in the foraging behaviour of gannets can indicate changes in food resources, often linked to variations in the marine environment.

Flying northern gannets with a Bird Solar GPS logger attached to the tail feathers. Photo: K. Borkenhagen. From Garthe S., et al. 2017.

Their work is part of a larger project called The Coastal Observing System for Northern and Arctic Seas, or COSYNA for short, which aims to better understand the complex interdisciplinary processes of northern seas and the Arctic coasts in a changing environment.

The German Bight

The waters of the northern seas and Arctic coasts are governed by a large range of natural processes and variables, such as wind, sea surface temperature and tides. In addition, the North Sea in particular, is heavily used for human activities: from shipping, to tourism, through to exploitation (and exploration) of food resources, energy and raw materials – making it of huge economic value and importance.

But it is precisely this heavy human activity which is contributing to change and disruptions in the region. Scientists know that the biochemistry, food webs, ecosystems and species of the North Sea are being altered. However, the causes of the change aren’t well quantified or understood and their consequences poorly defined. This means mitigating and adapting to the changes is proving hard for scientists and policy-makers alike.

Where progress and nature collide

In an area so heavily influenced by anthropogenic activities, it’s not unlikely that observed changes to the properties of the waters of the North Sea and the German Bight (where Heligoland is located) are driven, to some extent, by human actions.

Since 2008, 12 offshore wind farms have become operational in the German Bight and a further five are under construction; 15 more have been given building consent too. However, what impact (if any) wind farms have on seabirds is a hotly debated topic. Their effect on the hydrodynamics, biogeochemistry and biology of the North Sea is also poorly understood.

To unravel some of these questions, Garthe and his team tracked the movements of three individual gannets near existing wind farms in the North Sea. To find out their exact position, a GPS (mounted on the bird’s tail) was used and the flight tracks plotted on a map which also displayed the wind farms of the German Bight.

Overlap of flight patterns for the three northern gannets shown with the locations of wind farms in the German Bight. From Garthe S., et al. 2017.

Their results, published in the EGU’s open access journal Ocean Science, show that all three birds largely avoided the three wind farms just north of Heligoland. Though they visited sporadically, more often than not, the gannets flew around wind farms which also happened to be further away from their breeding grounds.

The team will now use the data acquired, which is of a much higher resolution than what has been available before, to understand how wind farms in the North Sea are affecting long-term seabird behaviour.

By Laura Roberts Artal, EGU Communications Officer.

References and further reading

Garthe, S., Peschko, V., Kubetzki, U., and Corman, A.-M.: Seabirds as samplers of the marine environment – a case study of northern gannets, Ocean Sci., 13, 337-347, https://doi.org/10.5194/os-13-337-2017, 2017.

Baschek, B., Schroeder, F., Brix, H., Riethmüller, R., Badewien, T. H., Breitbach, G., Brügge, B., Colijn, F., Doerffer, R., Eschenbach, C., Friedrich, J., Fischer, P., Garthe, S., Horstmann, J., Krasemann, H., Metfies, K., Merckelbach, L., Ohle, N., Petersen, W., Pröfrock, D., Röttgers, R., Schlüter, M., Schulz, J., Schulz-Stellenfleth, J., Stanev, E., Staneva, J., Winter, C., Wirtz, K., Wollschläger, J., Zielinski, O., and Ziemer, F.: The Coastal Observing System for Northern and Arctic Seas (COSYNA), Ocean Sci., 13, 379-410, https://doi.org/10.5194/os-13-379-2017, 2017.

Why do scientists measure sea surface temperature? (NOAA)

Scientists are putting seals to work to gather ocean current data (PRI)

Daunt, F., Peters, G., Scott, B., Grémillet, D., and Wanless, S.: Rapid-response recorders reveal interplay between marine physics and seabird behaviour, Mar. Ecol.-Prog. Ser., 255, 283–288, 2003.

Grémillet, D., Lewis, S., Drapeau, L., van der Lingen, C. D.,Huggett, J. A., Coetzee, J. C., Verheye, H. M., Daunt, F.,Wanless, S., and Ryan, P. G.: Spatial match–mismatch in the Benguela upwelling zone: should we expect chlorophyll and sea-surface temperature to predict marine predator distributions?, J. Appl. Ecol., 45, 610–621, 2008.

Wilson, R. P., Grémillet, D., Syder, J., Kierspel, M. A. M., Garthe, S., Weimerskirch, H., Schäfer-Neth, C., Scolaro, J. A., Bost, C.- A., Plötz, J., and Nel, D.: Remote-sensing systems and seabirds: their use, abuse and potential for measuring marine environmental variables, Mar. Ecol.-Prog. Ser., 228, 241–261, 2002.

Is it an earthquake, a nuclear test or a hurricane? How seismometers help us understand the world we live in

Is it an earthquake, a nuclear test or a hurricane? How seismometers help us understand the world we live in

Although traditionally used to study earthquakes, like today’s M 8.1 in Mexico,  seismometers have now become so sophisticated they are able to detect the slightest ground movements; whether they come from deep within the bowels of the planet or are triggered by events at the surface. But how, exactly, do earthquake scientists decipher the signals picked up by seismometers across the world? And more importantly, how do they know whether they are caused by an earthquake, nuclear test or a hurricane?

To find out we asked Neil Wilkins (a PhD student at the University of Bristol) and Stephen Hicks (a seismologist at the University of Southampton) to share some insights with our readers.


Seismometers are highly sensitive and they are able to detect a magnitude 5 earthquake occurring on the other side of the planet. Also, most seismic monitoring stations have sensors located within a couple of meters of the ground surface, so they can be fairly susceptible to vibrations at the surface. Seismologists can “spy” on any noise source, from cows moving in a nearby field to passing trucks and trains.

A nuclear test

On Sunday the 3rd of September, North Korea issued a statement announcing it had successfully tested an underground hydrogen bomb. The blast was confirmed by seismometers across the globe. The U.S.  Geological Survey registered a 6.3 magnitude tremor, located at the Punggye-ri underground test site, in the northwest of the country. South Korea’s Meteorological Administration’s earthquake and volcano center also detected what is thought to be North Korea’s strongest test to date.

However they occur, explosions produce ground vibrations capable of being detected by seismic sensors. Mining and quarry blasts appear frequently at nearby seismic monitoring stations. In the case of nuclear explosions, the vibrations can be so large that the seismic waves they produce can be picked up all over the world, as in the case of this latest test.

It was realised quite early in the development of nuclear weapons that seismology could be used to detect such tests. In fact, the need to have reliable seismic data for monitoring underground nuclear explosions led in part to the development of the Worldwide Standardized Seismograph Network in the 1960s, the first of its kind.

Today, more than 150 seismic stations are operating as part of the International Monitoring System (IMS) to detect nuclear tests in breach of the Comprehensive Test-Ban Treaty (CTBT), which opened for signatures in 1996. The IMS also incorporates other technologies, including infrasound, hydroacoustics and radionuclide monitoring.

The key to determining whether a seismic signal is from an explosion or an earthquake lies in the nature of the waves that are present. There are three kinds of seismic wave seismologists can detect. The fastest, called Primary (P) waves, cause ground vibrations in the same direction that they travel, similar to sound waves in the air. Secondary (S) waves cause shaking in a perpendicular direction. Both P and S waves travel deep through the Earth and are known collectively as body waves. In contrast, the third type of seismic waves are known as surface waves, because they are trapped close to the surface of the Earth. In an earthquake, it is normally surface waves that cause the most ground shaking.

In an explosion, most of the seismic energy is released outwards as the explosive material rapidly expands. This means that the largest signal in the seismogram comes as P waves. Explosions therefore have a distinctive shape in the seismic data when compared with an earthquake, where we expect S and surface waves to have higher amplitude.

Forensic seismologists can therefore make measurements of the seismic data to determine whether there was an explosion. An extra indication that a nuclear test occurred can also be revealed by measuring the depth of the source of the waves, as it would not be possible to place a nuclear device deeper than around 10 km below the surface.

Yet while seismic data can tell us that there has been an explosion, there is nothing that can directly identify that explosion as being nuclear. Instead, the IMS relies on the detection of radioactive gases that can leak from the test site for final confirmation of what kind of bomb was used.

The figure shows (at the bottom) the seismic recording of the latest test in North Korea made at NORSAR’s station in Hedmark, Norway. The five upper traces show recordings at the same station for the five preceding tests, conducted by North Korea in 2006, 2009, 2013 and 2016 (two explosions in 2016). The 2017 test, is as can be seen from this figure, clearly the strongest so far. Credit: NORSAR.

When North Korea conducted a nuclear test in 2013, radioactive xenon was detected 55 days later, but this is not always possible. Any detection of such gases depends on whether or not a leak occurs in the first place, and how the gases are transported in the atmosphere.

Additionally, the seismic data cannot indicate the size of the nuclear device or whether it could be attached to a ballistic missile, as the North Korean government claims.

What seismology can give us is an idea of the size of the explosion by measuring the seismic magnitude. This is not straightforward, and depends on knowledge of exactly how deep the bomb was buried and the nature of the rock lying over the test site. However, by comparing the magnitude of this latest test with those from the previous five tests conducted in North Korea, we can see that this is a much larger explosion.

The Norwegian seismic observatory NORSAR has estimated a blast equivalent to 120 kilotons of TNT, six times larger than the atomic bomb dropped on Nagasaki in 1945, and consistent with the expected yield range of a hydrogen bomb.

Hurriquakes?

Nuclear tests are not the only hazard keeping our minds busy in the past few weeks. In the Atlantic, Hurricanes Harvey, Irma and Katia have wreaked havoc in the southern U.S.A, Mexico and the Caribbean.

Hurricanes in the Atlantic can occur at any time between June and November. According to hurricane experts, we are at the peak of the season. It is not uncommon for storms to form in rapid succession between August, September and October.

The National Hurricane Centre (NHC) is the de facto regional authority for producing hurricane forecasts and issuing alerts in the Atlantic and eastern Pacific. For their forecasts, meteorologists use a combination of on the ground weather sensors (e.g. wind, pressure, Doppler radar) and satellite data.

As hurricane Irma tore its way across the Atlantic, gaining strength and approaching the Caribbean island of Guadeloupe, local seismometers detected its signature, sending the global press into a frenzy. It may come as a slight surprise to some people that storms and hurricanes also show on seismometers.

However, a seismometer detecting an approaching hurricane is not actually that astonishing. There is no evidence to suggest that hurricanes directly cause earthquakes, so what signals can we detect from a hurricane? Rather than “signals”, seismologists tend to refer to this kind of seismic energy as “noise” as it thwarts our ability to see what we’re normally looking out for – earthquakes.

The seismic noise from a storm doesn’t look like distinct “pings” that we would see with an earthquake. What we see are fairly low-pitched “hums” that gradually get louder in the days and hours preceding the arrival of a storm. As the storm gets closer to the sensor, these hums turn into slightly higher-pitched “rustling”. This seismic energy then wanes as the hurricane drifts away. We saw this effect clearly for Hurricane Irma with recordings from a seismometer on the island of Guadeloupe.

What causes these hums and rustles? If you look at the frequency content of seismic data from any monitoring station around the globe, noise levels light up at frequencies of ~0.2 Hz (5 s period). We call these hums “microseism”. Microseism is caused by persistent seismic waves unrelated to earthquakes, and it occurs over huge areas of the planet.  One of the strongest sources of microseism is caused by ocean waves and swell. During a hurricane, swell increases and ocean waves become more energetic, eventually crashing into coastlines, transferring seismic energy into the ground. This effect is more obvious on islands as they are surrounded by water.

As the hurricane gets closer to the island, wind speeds dramatically increase and may dwarf the noise level of the longer period microseism. Wind rattles trees, telegraph poles, and the surface itself, transferring seismic energy into the ground and moving the sensitive mass inside the seismometer. This effect causes higher-pitched “rustles” as the centre of the storm approaches. Gusts of wind can also generate pressure changes inside the seismometer installation and within the seismometer itself, generating longer period fluctuations.

During Hurricane Irma, a seismic monitoring station located in the Dutch territory of St. Maarten clearly recorded the approach of the storm, leading to an intense crescendo as the eyewall crossed the area. As the centre of the eye passed over, the seismometer seems to have recorded a slightly lower noise level. This observation could be due to the calmer conditions and lower pressure within the eye. The station went down shortly after, probably from a power outage or loss in telemetry which provides the data in real-time.

Seismometers measuring storms is not a new observation. Recently, Hurricane Harvey shook up seismometers located in southern Texas. Even in the UK, the approach of winter storms across the Atlantic causes much higher levels of microseism.

It would be difficult to use seismometer recordings to help forecast a hurricane – the recordings really depend on how close the sensor is to the coast and how exposed the site is to wind. In the event of outside surface wind and pressure sensors being damaged by the storm, protected seismometers below the ground could possibly prove useful in delineating the rough location of the hurricane eye, assuming they maintain power and keep sending real-time data.

At least several seismic monitoring stations in the northern Antilles region were put out of action by the effects of the Hurricane. Given the total devastation on some islands, it is likely that it will take at least several months to bring these stations back online. The Lesser Antilles are a very tectonically active and complex part of Earth; bringing these sensors back into operation will be crucial to earthquake and volcano hazard monitoring in the region.

By Neil Wilkins (PhD student at the University of Bristol) and Steven Hicks (a seismologist at the University of Southampton)

References and further reading

GeoSciences Column: Can seismic signals help understand landslides and rockfalls?

NORSAR Press Release: Large nuclear test in North Korea on 3 September 2017

The Comprehensive Nuclear-Test-Ban Organization Press Release: CTBTO Executive Secretary Lassina Zerbo on the unusual seismic event detected in the Democratic People’s Republic of Korea

First Harvey, Then Irma and Jose. Why? It’s the Season (The New York Times)

NOAA  National Hurricane Center

IRIS education and outreach series: How does a seismometer work?

August GeoRoundUp: the best of the Earth sciences from around the web

August GeoRoundUp: the best of the Earth sciences from around the web

Drawing inspiration from popular stories on our social media channels, as well as unique and quirky research news, this monthly column aims to bring you the best of the Earth and planetary sciences from around the web.

Major Stories

On August 25th Hurricane Harvey made landfall along the southern coast of the U.S.A, bringing record breaking rainfall, widespread flooding and a natural disaster on a scale not seen in the country for a long time. In fact, it’s the first time since 2005 a major hurricane has threatened mainland U.S.A. – a record long period.

But Harvey’s story began long before it brought destruction to Texas and Louisiana.

On August 17th,the National Space Agency (NASA) satellite’s first spotted a tropical depression forming off the coast of the Lesser Antilles. From there the storm moved into the eastern Caribbean and was upgraded to Tropical Storm Harvey where it already started dropping very heavy rainfall. By August 21st, it had fragmented into disorganised thunderstorms and was spotted near Honduras, where heavy local rainfall and gusty winds were predicted.

Over the next few days the remnants of the storm travelled westwards towards Nicaragua, Honduras, Belize and the Yucatan Peninsula. Forecasters predicted that, owing to warm waters of the Gulf of Mexico and favorable vertical wind shear, there was a high chance the system could reform once it moved into the Bay of Campeche (in the southern area of the Gulf of Mexico) on August 23rd. By August 24th data acquired with NASA satellites showed Harvey had began to intensify and reorganise. Heavy rainfall was found in the system.

Harvey continued to strengthen as it traveled across the Gulf of Mexico and weather warnings were issued for the central coast of Texas. Citizens were told to expect life-threatening storm surges and freshwater flooding. On August 25th, Harvey was upgraded to a devastating Category 4 hurricane, when sustained wind speeds topped 215 kph.

Since making landfall on Friday and stalling over Texas (Louisiana is also affected) – despite being downgraded to a tropical storm as it weakened – it has broken records of it’s own. “No hurricane, typhoon, or tropical storm, in all of recorded history, has dropped as much water on a single major city as Hurricane Harvey is in the process of doing right now in Houston (Texas)”, reports Forbes. In fact, the National Weather Service had to update the colour charts on their graphics in order to effectively map it. This visualisation maps Harvey’s destructive path through Texas.

A snaptshot from the tweet by the official Twitter account for NOAA’s National Weather Service.

So far the death toll is reported to be between 15 to 23 people, with the Houston Police Chief saying 30,000 people are expected to need temporary shelter and 2,000 people in the city had to be rescued by emergency services (figures correct at time of writing).

Many factors contributed toward making Hurricane Harvey so destructive. “The steering currents that would normally lift it out of that region aren’t there,” J. Marshall Shepherd, director of the atmospheric sciences program at the University of Georgia, told the New York Times. The storm surge has blocked much of the drainage which would take rainfall away from inland areas. And while it isn’t possible to say climate change caused the hurricane, “it has contributed to making it worse”, says Michael E Mann. The director of the Earth System Science Center at Pennsylvania State University argues that rising sea levels and ocean water temperatures in the region (brought about by climate change) contributed to greater rainfall and flooding.

A man carries his cattle on his shoulder as he moves to safer ground at Topa village in Saptari. Credit: The Guardian.

While all eyes are on Houston, India, Bangladesh and Nepal are also suffering the consequences of devastating flooding brought about a strong monsoon. The United Nations estimates that 41 million people are affected by the disaster across the three countires. Over 1200 people are reported dead. Authorities are stuggling with the scale of the humanitarian crisis: “Their most urgent concern is to accessing safe water and sanitation facilities,” the UN Office for the Coordination of Humanitarian Affairs (OCHA) said earlier this week, citing national authorities. And its not only people at risk. Indian authorities reported large swathes of a famous wildlife reserve park have been destroyed. In Mumbai, the downpour caused a building to collapse killing 12 people and up to 25 more are feared trapped.Photo galleries give a sense of the scale of the disaster.

Districts affected by flooding. Credit: Guardian graphic | Source: ReliefWeb. Data as of 29 August 2017

What you might have missed

In fact, it’s highly unlikely you missed the coverage of this month’s total solar eclipse over much of Northern America. But on account of it being the second biggest story this month, we felt it couldn’t be left out of the round-up. We particularly like this photo gallery which boasts some spectacular images of the astronomical event.

This composite image, made from seven frames, shows the International Space Station, with a crew of six onboard, as it transits the Sun at roughly five miles per second during a partial solar eclipse, Monday, Aug. 21, 2017 near Banner, Wyoming. Credit: (NASA/Joel Kowsky)

Since the end of July, wildfires have been raging in southwest Greenland. While small scale fires are not unheard of on the island otherwise known for its thick ice cap and deep fjords, the fires this month are estimated to extend over 1,200 hectares. What started the fires remains unknown, as do the fuel sources and the long-term impacts of the burn.

The U.S.A’s National Oceanic and Atmospheric Administration highlighted that the fires are a source of sooty “black carbon”. As the ash falls on the pristine white ice sheet, it turns the surface black, which can make it melt faster. Greenland police recently reported that unexpected rain haf all but extinguished the massive fires; though the situation continues to be monitored, as smouldering patches run the risk of reigniting the flames.







Links we liked

The EGU story

Do you enjoy the EGU’s annual General Assembly but wish you could play a more active role in shaping the scientific programme? Now is your chance! Help shape the scientific programme of EGU 2018.

From today, until 8 Sep 2017, you can suggest:

  • Sessions (with conveners and description), or;
  • Modifications to the existing skeleton programme sessions
  • NEW! Suggestions for Short courses (SC) will also take place during this period
  • From now until 18 January 2018, propose Townhall and splinter meetings

And don’t forget! To stay abreast of all the EGU’s events and activities, from highlighting papers published in our open access journals to providing news relating to EGU’s scientific divisions and meetings, including the General Assembly, subscribe to receive our monthly newsletter.
