Humanitarian groundwater projects; notes on motivations from the academic world

Humanitarian groundwater projects; notes on motivations from the academic world

Post by Margaret Shanafield, ARC DECRA Senior Hydrogeology/Hydrology Researcher at Flinders University, in Australia. You can follow Margaret on Twitter at @shanagland.

___________________________________________________________

What led me down the slippery slope into a career in hydrology and then hydrogeology, was a desire to combine my love of traveling with a desire to have a deeper relationship with the places I was going, and be able to contribute something positive while there. I figured everyone needs water, and almost everyone has either too much (flooding) or too little of it.

But, from an academic point of view, aid/humanitarian/philanthropic projects can be frustrating and offer few of the traditional paybacks that universities and academia reward.  Last week, for example, I spent much of my time working on the annual report for an unpaid project, and I am soft money funded. And what’s worse, I couldn’t even get the report finished, because most of the project partners hadn’t given me their updates on time. When I went across the hall to complain to my colleague, he admitted that he, too, was in a similar situation.

So what is the incentive?

Globally, the need for regional hydrologic humanitarian efforts is obvious. Even today, 1,000 children die due to diarrhoeal diseases on a daily basis. Water scarcity affects 40% of global population, with 1.7 billion people dependent on groundwater basins where the water extraction is higher than the recharge.  And, the lack of water availability is only going to get worse into the future.

But being a researcher with pressure to “publish or perish” and find ways to fund myself and my research, what was/is my incentive to address these problems? From an academic point of view, water aid projects are often time-consuming, with expected timelines delayed by language and cultural barriers, difficulties in obtaining background data, expectations on each side of the project not matching up, and activities and communication not happening on the timescales academics are used to. And the results are typically hard to publish.

An online search revealed numerous articles discussing the pros and cons of pursuing a career in development work, including: having a job aligned with one’s morals and values, an exciting lifestyle full of change, motivated co-workers, the opportunity to see the world and different cultures, the opportunity to make a difference, and last but not least, because it is a challenge (in a good way).

As a scientist, I get elements of all these pros in my daily work. But, while much of what academics do fits under the umbrella of “intellectually challenging”, aid projects provide applied problems with real-world implications that can sometimes be lacking in the heavily research-focused academic realm, except for the creative “broader impacts” and outreach sections of grant proposals. They are therefore an opportunity for scientists to have an impact on the world by contributing to the collective understanding of water resources and hydrologic systems. And hey, many of us enjoy travelling and get to visit interesting places for work, too.

Pulling myself out of my philosophical waxings, I focused on these highlights and the benefits of working in an interdisciplinary project to address some of those global problems I mentioned earlier – and got back to report writing.

Training project partners in Vietnam to take shallow geophysical measurements (left). Sweaty days in the field are rewarded by cheap beers, magnificent sunrises, and relaxing evenings at the coast where the river meets the sea (right). Photos by M Shanafield.

___________________________________________________________

Margaret Shanafield‘s research is at the nexus between hydrology and hydrogeology. Her current research interests still focus on surface water-groundwater actions, although she work’s on a diverse set of projects from international development projects to ecohydrology. The use of multiple tracers to understand groundwater recharge patterns in streambeds and understanding the dynamics of intermittent and ephemeral streamflow are her main passions. Since 2015, she has been an ARC DECRA fellow, measuring and modelling what hydrologic factors lead to streamflow in arid regions. You can find out more about Margaret on her website.

Good groundwater management makes for good neighbors

Good groundwater management makes for good neighbors

Post by Samuel Zipper, postdoctoral fellow at both McGill University and the University of Victoria, in Canada. You can follow Sam on Twitter at @ZipperSam.

___________________________________________________________

Dedicated Water Underground readers know that this blog is not just about water science, but also some of the more cultural impacts of groundwater. Keeping in that tradition, today’s post begins with a joke*:

Knock, knock!

Who’s there?

Your neighbor

Your neighbor who?

Your neighbor’s groundwater, here to provide water for your plants!

Figure 1. Typical reaction to joke written by the author.

Ahem.

Perhaps this joke needs a little explanation. As we’ve covered before, groundwater is important not just as a supply of water for humans, rivers, and lakes, but also because it can increase the water available to plants, making ecosystems more drought resistant and productive. However, we also know that groundwater moves from place to place beneath the surface. This means that human actions which affect groundwater in one location, like increasing the amount of paved surface, might have an unexpected impact on ecosystems in nearby areas which depend on that groundwater.

Imagine, for example, two neighboring farmers. Farmer A decides retire and sells his land to a developer to put in a new, concrete-rich shopping center. Farmer B continues farming her land next door. How will the changes next door affect the groundwater beneath Farmer B’s land, and will this help or hurt crop production on her farm?

In a new study, my colleagues and I explored these questions using a series of computer simulations. We converted different percentages of a watershed from corn to concrete to see what would happen. Our results showed that the response of crops to urbanization depended on where the land use change occurred.

Figure 2. Conceptual diagram showing how urbanization might impact crop yield elsewhere in a watershed. From Zipper et al. (2017).

In upland areas where the water table was deep, replacing crops with concrete caused a reduction in groundwater recharge, lowering the water table everywhere in the watershed – not just beneath the places where urbanization occurred. This meant that places where the ecosystems used to be reliant on groundwater could no longer tap into this resources, making them more vulnerable to drought. However, places where the water table used to be too shallow saw boosts in productivity, as the lower water table was closer to the optimum water table depth.

In contrast, urbanization happening in lowland areas had a much more localized effect, with changes to the water table and yield occurring primarily only in the location where land use changed, because the changes in groundwater recharge were accounted for by increased inflows from the stream into the groundwater system.

So, what does this mean for the neighboring farmers we met earlier?

For Farmer A, it means the neighborly thing to do is work with the developers to minimize the effects of the land use change on groundwater recharge. This can include green infrastructure practices such as rain gardens or permeable pavement to try and mimic predevelopment groundwater recharge.

For Farmer B, the impacts depend on the groundwater depth beneath her farm. If the groundwater beneath her farm is shallow enough that her crops tap into that water supply, she should expect changes in the productivity of her crops, especially during dry periods, and plan accordingly.

*Joke written by scientist, rather than actual comedian.

___________________________________________________________

For More Information:

Zipper SC, ME Soylu, CJ Kucharik, SP Loheide II. Indirect groundwater-mediated effects of urbanization on agroecosystem productivity: Introducing MODFLOW-AgroIBIS (MAGI), a complete critical zone model. Ecological Modelling, 359: 201-219. DOI: 10.1016/j.ecolmodel.2017.06.002

___________________________________________________________



Sam Zipper is an ecohydrologist. His main research focuses broadly on interactions between vegetation and the water cycle, with a particular interest in unintended or indirect impacts of land use change on ecosystems resulting from altered surface and subsurface hydrological flowpaths. You can find out more about Sam by going to his webpage at: samzipper.weebly.com.

Of Karst! – short episodes about karst

Of Karst! – short episodes about karst

Episode 2: Dissolving rock? (or, how karst evolves).

Post by Andreas Hartmann, Lecturer in Hydrology at the University of Freiburg (Universität Freiburg), in Germany. You can follow Andreas on twitter at @sub_heterogenty.

Didn’t get to read Episode 1? Click this link here to do so!

___________________________________________________________

In the previous episode, I introduced karst by showing how it looks in different regions in the world. This episode will now deal with the processes that create such amazing surface and subsurface landforms. The widely used term “karstification” refers to the chemical weathering of easily soluble rock composed of carbonate rock or gypsum. Most typical is karstification of limestone (consisting of the mineral calcite, CaCO3) or dolostone (consisting of the mineral dolomite, CaMg(CO3)2). If exposed to CO2 rich water these rocks are dissolved to form aqueous calcium (Ca2+) or magnesium (Mg2+) and bicarbonate (HCO3 ) ions. For calcite, karstification is described by the following chemical equilibrium:

The dissolution of carbonate rock depends on various factors. Imagine a solid block of salt, which you pour water on. If completely solid, the water will flow down the salt surface slowly dissolving the block. If fractured, water will eventually enlarge the fractures in the salt block and dissolution will occur much faster. Now imagine smashing the salt block before pouring water on it. In such circumstances the salt will dissolve even faster as the surface area exposed to the water is much larger.

Karst and its evolution (educational video provided by Jennifer Calva on Youtube).

The same is true for karstification. If the carbonate rock is heavily fractured, it will dissolve faster than unfractured carbonate rock. Another factor is the availability of CO2, that depends on the relative amount of CO2 in the air, air temperature and soil microbiotic processes. Other factors are the purity of the carbonate rock, the availability of water, and the supply of CO2 from the surface. As soon as karstification takes place, more water will be able to pass the dissolution enlarged fractures providing more and more CO2, and creating a positive feedback between rock dissolution and water flow:

Positive feedback between carbonate rock dissolution and water flow (Hartmann et al., 2014, modified).

The hydrochemical processes described in this episode of the Of Karst! Series not only create beautiful karst landscapes but they also have a strong and particular impact on water flow paths in the subsurface, which will the topic of episode 4 that can be expected in early 2018. Before, I will present a special feature about karst in the movies as topic of episode 3 in autumn 2017.

Further reading

Hartmann, A., Goldscheider, N., Wagener, T., Lange, J. & Weiler, M. 2014. Karst water resources in a changing world: Review of hydrological modeling approaches. Reviews of Geophysics, 52, 218–242, doi: 10.1002/2013rg000443.

Ford, D.C. & Williams, P.W. 2013. Karst Hydrogeology and Geomorphology. John Wiley & Sons, 576 pages.

___________________________________________________________





Andreas Hartmann is a lecturer in Hydrology at the University of Freiburg. His primary field of interest is karst hydrology and hydrological modelling. Find out more at his personal webpage www.subsurface-heterogeneity.com.



Groundwater & Education – Part One

Groundwater & Education – Part One

Post by Viviana Re, postdoctoral researcher at the University of  Pavia (Università di Pavia), in Italy. You can follow Viviana on Twitter at @biralnas.

Part one of a two part series on groundwater and education by Viviana.

___________________________________________________________

Education /ɛdjʊˈkeɪʃ(ə)n
The process of receiving or giving systematic instruction, especially at a school or university.

  • from Latin educatio(n-), from the verb educare
  • Educare is a combination of the words e (out) and ducare (lead, drawing), or drawing out.

Based on this definition, I should change the title of this post to: Drawing out groundwater (from the well). This is actually the main occupation of groundwater scientists, isn’t it? Not only are we always withdrawing groundwater from a well or a borehole while sampling, but we also often have to “draw it out” when dealing with managers and policy makers, as sometimes they seem to forget about this hidden (but very important) component of the water cycle. Therefore, we are quite used to these forms of “drawing out” – but what about education? Are we really that effective in “drawing out” groundwater in explaining its peculiarities, issues, and connections within the whole water cycle and, more generally, with the environment?

Indeed, the effort of shedding light on something that is not so visible nor easily studied has the side effect of forcing us to focus solely on it, with a resulting tendency of developing sectorial approaches to water management.

In the preface of a UNESCO Technical paper, I found the following excerpt: “Water resources schemes are now increasingly considered as integrated systems and consequently, civil engineers, geologists, agricultural engineers and hydraulic engineers engaged in planning and design no longer work in isolation”. The document is dated 1974 but, still in 2017, we are somehow struggling to fitting groundwater into Integrated Water Resources Management (IWRM) and to connecting mental and structural “silos”. Quoting Daly (2017), the latter is particularly relevant (especially when education is at stake): if on the one hand, specialization can be the driver for a sound knowledge; on the other hand, this can encourage people to get stuck in their own individual disciplines (or said in other words, their “silos”). Indeed, “silos” exist in their structures, but can also exist as a state of mind that can go hand in hand with tunnel vision (Tett, 2015).

Therefore, in my opinion, the new generation of groundwater scientists (and teachers) should have a new mission: to work (and therefore, to teach) coherently with the integrated and complex nature of the water cycle. In fact, the role of hydrogeologists and groundwater scientists in times of increasing freshwater demand, exacerbated by population growth and climate change effects, requires a serious shift towards a more holistic approach targeting sound groundwater assessment and long-term management.

Arguably, if we are still discussing possible ways of practically implementing this integration, we should definitely start asking ourselves if the the “business as usual” way of working and teaching is effective.  If it is not, we must begin investigating how we can go beyond classical approaches to draw groundwater out of the well.

Playing with kids while sampling … can we call it capacity building?!



To be continued …

[Read More]

What is the difference between ‘water withdrawal’ and ‘water consumption’, and why do we need to know?

What is the difference between ‘water withdrawal’ and ‘water consumption’, and why do we need to know?

Post by Inge de Graaf, University of Freiburg, Environmental Hydrological Systems group

________________________________________________________________________________________________________________

Last week I had to teach my first class in global hydrology. When I showed the global trend on increasing demands and withdrawals (see Figure) I needed to explain the different terms as sometimes the term “water use” gets, well, misused.

The term “water use” often fails to adequately describe what happens to the water. So I told the students; if you see or hear to term ‘water use’ always ask yourself what’s actually being said. The term is often used for water withdrawals or water consumption, and it’s important to understand the difference.

Water withdrawal describes the total amount of water withdrawn from a surface water or groundwater source. Measurements of this withdrawn water help evaluate demands from domestic, industrial and agricultural users.

Water consumption is the portion of the withdrawn water permanently lost from its source. This water is no longer available because it evaporated, got transpired or used by plants, or was consumed by people or livestock. Irrigation is by far the largest water consumer. Globally irrigated agriculture accounts for 70% of the total water used and almost 50% is lost either by evaporation or transpiration.

Understanding both water withdrawal and consumption is critical to properly evaluate water stress. Measurements of water withdrawal indicate the level of competition and dependence on water resources. Water consumption estimates help to quantify the impact of water withdrawals on downstream availabilities and are essential to evaluate water shortage and scarcity. For example, most water used by households is not consumed and flows back as return flow and can be reused further downstream. However, water is rarely returned to watershed after being used by households or industry without changing the water quality, increasing water stress levels.

Already more than 1.4 billion people live in areas where the withdrawal of water exceeds recharge rates. In the coming decades global population is expected to increase from 7.3 billion now, to 9.7 billion by 2050 (UN estimate). This growth, along with rising incomes in developing countries, is driving up global food demands. With food production estimated to increase by at least 60% (FAO estimate), predicting water withdrawal and consumption is critically important for identifying areas that are at risk of water scarcity and where water use is unsustainable and competition amongst users exist.

Global trend I showed in my class, published in Wada et al (2016).

Ref:

Wada, Y., I. E. M. de Graaf, and L. P. H. van Beek (2016), High-resolution modeling of human and climate impacts on global water resources, J. Adv. Model. Earth Syst., 8, 735–763, doi:10.1002/2015MS000618.



How prehistoric water pit stops may have driven human evolution

How prehistoric water pit stops may have driven human evolution

Post by Matthew Robert Bennett, Bournemouth University and Mark O Cuthbert, Cardiff University

Our ancient ancestors seem to have survived some pretty harsh arid spells in East Africa’s Rift Valley over five million years. Quite how they kept going has long been a mystery, given the lack of water to drink. Now, new research shows that they may have been able to survive on a small networks of springs.

The study from our inter-disciplinary research team, published in Nature Communications, illustrates that groundwater springs may have been far more important as a driver of human evolution in Africa than previously thought.

Great rift valley.Redgeographics, CC BY-SA

The study focuses on water in the Rift Valley. This area – a continuous geographic trench that runs from Ethiopia to Mozambique – is also known as the “cradle of humanity”.

Here, our ancestors evolved over a period of about five million years. Throughout this time, rainfall was affected by the African monsoon, which strengthened and weakened on a 23,000-year cycle. During intense periods of aridity, monsoon rains would have been light and drinking water in short supply. So how did our ancestors survive such extremes?

Previously, scientists had assumed that the evolution and dispersal of our ancestors in the region was solely dependent on climate shifts changing patterns of vegetation (food) and water (rivers and lakes). However, the details are blurry – especially when it comes to the role of groundwater (springs).

We decided to find out just how important springs were. Our starting point was to identify springs in the region to map how groundwater distribution varies with climate. We are not talking about small, babbling springs here, but large outflows of groundwater. These are buffered against climate change as their distribution is controlled by geology – the underlying rocks can store rainwater and transfer it slowly to the springs.

The lakes of the African Rift Valley.SeaWiFS Project, NASA/Goddard Space Flight Center, and ORBIMAGE

We figured that our ancestors could have stayed close to such groundwater in dry times – playing a greater part in their survival than previously thought. When the climate got increasingly wet, groundwater levels would have risen and made springs more plentiful – feeding smaller rivers and leading to lakes becoming less saline. At this point, our ancestors would have roamed across the landscape free of concerns about water.

Life and death decisions

To test this idea, we embarked on a computer experiment. If the springs and water bodies are thought of as the rest stops, or service stations, then the linkages between can be modelled by computers. Our model was based on what decisions individuals would have taken to survive – and what collective behaviours could have emerged from thousands of such decisions.

Individuals were give a simple task: to find a new source of water within three days of travel. Three days is the time that a modern human and, by inference, our ancestors could go without drinking water. The harder and rougher the terrain, the shorter the distance one can travel in those vital three days.

We used the present landscape and existing water springs to map potential routes. The detailed location of springs may have changed over time but the principles hold. If our agent failed to find water within three days, he or she would die. In this way we could map out the migration pathways between different water sources as they varied through 23,000-year climate cycles. The map shows that there were indeed small networks of springs available even during the driest of intervals. These would have been vital for the survival or our ancestors.

The model also reveals movement patterns that are somewhat counter-intuitive. One would assume that the easiest route would be along the north to south axis of the rift valley. In this way, hominins could stay at the bottom of the valley rather than crossing the high rift walls. But the model suggests that in intermediate states between wet and dry, groups of people may have preferred to go from east to west across the rift valley. This is because springs on the rift floor and sides link to large rivers on the rift flanks. This is important as it helps explain how our ancestors spread away from the rift valley. Indeed, what we are beginning to see is a network of walking highways that develop as our ancestors moved across Africa.

Mapping human migration.

Human movement allows the flow of gossip, know-how and genes. Even in modern times, the water-cooler is often the fount of all knowledge and the start of many budding friendships. The same may have been true in ancient Africa and the patterns of mobility and their variability through a climate cycle will have had a profound impact on breeding and technology.

This suggests that population growth, genetics, implications for survival and dispersal of human life across Africa can all potentially be predicted and modelled using water as the key – helping us to uncover human history. The next step will be to compare our model of human movement with real archaeological evidence of how humans actually moved when the climate changed.

So next time you complain about not finding your favourite brand of bottled spring water in the shop, spare a thought for our ancestors who may died in their quest to find a rare, secluded spring in the arid African landscape.

The ConversationThis research was carried out in partnership with our colleagues Tom Gleeson, Sally Reynolds, Adrian Newton, Cormac McCormack and Gail Ashley.

Matthew Robert Bennett, Professor of Environmental and Geographical Sciences, Bournemouth University and Mark O Cuthbert, Research Fellow in Groundwater Science, Cardiff University

This article was originally published on The Conversation. Read the original article.

How did our planet get its water?

How did our planet get its water?

Post by WaterUnderground contributors Elco Luijendijk and Stefan Peters from  the University of Göttingen, in Germany.

After my first ever scientific presentation, someone in the audience asked a question that caught me off guard: “Where does the groundwater come from?”.  “Ehm, from rainfall”, I answered. The answer seemed obvious at the time. However, we did not realize at the time that this is actually a profound question in hydrogeology, and one that is rarely addressed in hydrology textbooks and courses: “How did our planet get its water?”. To find out how far science has come to answering this question I (EL) joined up with a geochemist and meteorite expert (SP) to write this blog post.

We are lucky to live on a planet of which ~71% of the surface is covered with water, located mostly in rivers, lakes, glaciers and oceans at the surface and as groundwater in the shallow subsurface. Liquid water sustains life on our planet and seems to play a critical role in plate tectonics. And incidentally, it also to gives hydrogeologists something to study. Liquid water is so important in sustaining life, that the search for life on other planets in our solar system or beyond always focuses first on finding planets with liquid water.

Not only do we have abundant liquid water, we seem to have just the right amount. Compared to our direct planetary neighbors, Mars and Venus, we are extremely lucky. On the surface of Mars, at present, water mainly occurs as ice, whereas tiny amounts of water vapor are present in the Martian atmosphere. Venus also has minute amounts of water vapor in the atmosphere, but its blazingly hot surface is entirely devoid of water. In contrast to Mars and Venus, some objects in the solar system that are further away actually have too much water. Take for instance Enceladus, a moon of the planet Saturn, at which an icy crust overlies a 10 km deep water ocean. The amount of water on Enceladus is so large that it causes a wobble in the rotation of this moon, which is one of the reasons why this large volume of water was discovered in the first place. Clearly Enceladus is great for ice-skating, but probably not for sustaining land-based life similar to humans.

Figure 1: From left to right, Venus, Earth and Mars. Which one would you like to live on? Source: ESA (link) .

So how did we on Earth get so lucky?

It turns out that this depends on which scientist you ask. There are two theories:
Theory 1: The major building blocks of the Earth contained water from the start. This water then accumulated at the surface of our planet (by “degassing” from the mantle) and formed the oceans and the hydrosphere.
Theory 2: The major building blocks of the Earth were bone dry, and most of the water was delivered by comets and water-rich asteroids some time after most of our planet’s mass had formed by accretion.
So far, scientists do not have reasons to discard either of these theories, but there are two important arguments in favor of water being delivered after most of the planet had already formed:

Earth formed in a hot region of the solar system from which molecules with “low” condensation temperatures such as water had largely been removed before planetary accretion started (Albarède, 2009). Secondly, the ratio of heavy to light water in Earth’s oceans is similar to that of water in some comets and asteroids (Hartogh et al., 2011). Although you may not have noticed this when you last opened your water tap, a very small fraction (0.016 %) of the water on our planet is heavy, because it contains an extra neutron. The similarity in heavy water composition between asteroids and comets and Earth’s oceans does not prove that water on Earth was delivered by comets, but it certainly is consistent with this scenario. To make matters more complicated, however, the recent European space agency mission Rosetta to the water-rich comet 67P/Churyumov–Gerasimenko found that it has a very different ratio of heavy to light water than our oceans, which certainly complicates the debate.

Figure 2 Comet 67P/Churyumov-Gerasimenko losing water (and dust) as it gets closer to the sun. Source: ESA

Interestingly, neither theory can directly explain why our direct planetary neighbors, Mars and Venus, are so dry compared to Earth. So is it possible that these planets once were similar to Earth, and contained more water in their early days than that they do now?

Due to the high surface temperatures at Venus, any liquid water near the surface would immediately evaporate and diffuse into the atmosphere of the planet as a gas. We know that due to the lack of a protective magnetic field on Venus, solar winds continuously erode the atmosphere of the planet. If Venus had abundant water in the past, such erosion by solar winds would therefore have effectively stripped water from the planet’s atmosphere. Similar to Venus, Mars also does not have a protective magnetic field, but the temperatures and pressures at the Martian surface are significantly lower than at Venus’ surface, allowing water to be present at the surface as ice. In fact, Mars may have had a denser atmosphere in the past that allowed liquid water to be present at the surface. Nowadays, erosional features such as channels are the dry witnesses that water indeed once occurred as a liquid on the surface of the planet.

Figure 3. Dry channels (in inverted relief) in the Eberswalde delta on Mars as seen by NASA’s Mars Global Surveyor (link)

As a summary, we have an idea on why our planet was lucky enough to keep large amounts of water compared to Venus and Mars. However, do we know how our planet got its water in the first place? Unfortunately we are still not sure. There is hope though: we keep getting closer to the answer thanks to recent research on the composition of water on our planet and comets and asteroids in the solar system. So stay tuned, there’s a good chance that science will be able to answer this question in the coming years…

References
Hartogh, P. et al. (2011), Ocean-like water in the Jupiter-family comet 103P/Hartley 2, Nature, 478(7368), 218–220.
Albarède, F. (2009). Volatile accretion history of the terrestrial planets and dynamic implications. Nature, 461(7268), 1227-1233.

Limits to global groundwater use

Limits to global groundwater use

Post by WaterUnderground contributor Inge de Graaf. Inge is a postdoc fellow at Colorado School of Mines, in the USA.

Groundwater is the world’s most important source of freshwater. It supplies 2 billion people with drinking water and is used for irrigation of the largest share of the world’s food supply.

However, in many regions around the world, groundwater reserves are depleting as the resource is being pumped faster than it is being renewed by rain infiltrating through the soil. Additionally, in many cases, we are still clueless about how long we can keep drawing down these water reserves before groundwater depletion will have devastating impacts on environmental and socio-economic systems. Indeed, these devastating effects are already being observed.

The most direct effect of groundwater depletion is the decline in groundwater levels. As a direct impact, groundwater-pumping cost will increase, so too will the cost of well replacement and the cost of deepening wells. One of the indirect consequences of declining water levels is land subsidence, which is the gradual sinking of the surface. In many coastal and delta cities, increased flooding results in damages totaling billions of dollars per year. Next to this, declining groundwater levels lead to a decrease in groundwater discharge to rivers, wetlands, and lakes, resulting in rivers running dry, wetlands that are no longer sustained, and groundwater-dependent ecosystems that are harmed.

Over the past decades, global groundwater demands have more than doubled. These demands will continue to increase due to population growth and climate change.

The increase in demands and the aforementioned negative effects of groundwater depletion raise the urgent question: at what time in future are the limits to global groundwater use reached? This is when and where groundwater levels drop to a level where groundwater becomes unattainable for abstraction, or that groundwater baseflows no longer sustain river discharges.

In my PhD research, I predicted where and when we will reach these limits of groundwater consumption worldwide. I defended my dissertation last year April at Utrecht University, in the Netherlands.

Where and when are the limits reached?

Results show that many large aquifer systems are already highly depleted, especially for intensively irrigated areas in dryer regions of the world, like India, Pakistan, Mid West USA, and Mexico (see Figure 1). New areas experiencing groundwater depletion will develop in the near future, such as Eastern Europe and Africa. Future predictions show that some areas, like the Central Valley, and the High Plains Aquifer, partly recover when more recharge will becomes available. Notwithstanding, environmental groundwater demands will increase as to buffer more irregular streamflow occurrences due to climate change.

Figure 1: Estimated groundwater depletion (1960-2010) in [m], masked for aquifer areas, and zooms for hotspot regions, which are the intensively irrigated regions of the world.

In 2010, about 20% if the world population lived in groundwater depleted regions, where groundwater dropped below the economical exploitable limit. As a rule of thumb: the economic limit is reached when groundwater becomes unattainable for a local farmer, which is approximately when the water level drops to 100 m below the surface. In 2050, 26% to 36% of the world’s population will live in areas where the economic exploitable limit is reached (see Figure 2). Evidently, this persistence and increasing level of groundwater stress will impair local development and generate tension within the global socio-economic system.

Figure 2: First time that groundwater falls below the 100m limit.



Global-scale simulations

To answer my main question, I studied the effects of groundwater abstractions on river low flows and groundwater levels worldwide, as well as which trends in river low flow frequency and groundwater level change can be attributed to groundwater abstractions.

I used a newly developed physically based surface water-groundwater model to simulate i.a. river flows, lateral groundwater flow, and groundwater-surface water interactions at a high resolution (approx. 10×10 km) at the global scale. Total water demands were estimated and account for agricultural, industrial, and domestic demands. I simulated groundwater and surface water abstractions based on the availability of the resource, making the estimate reliable for future projections under climate change and for data-poor regions where we do not know how much groundwater or surface water is abstracted. Next, I developed a global-scale groundwater model. I estimated alluvial aquifer thickness worldwide, as no data at the global scale is available (see Figure 3). Aquifer thickness is one of the parameters you need to estimate groundwater flow and storage.

Figure 3: Estimated alluvial aquifer thickness. White areas are mountain regions, where no aquifers are simulated.

Simulations were done for the recent past and near future (1960-2050) and the results include maps and trends of groundwater heads, groundwater fluctuations, and river discharges.

In conclusion, most of our water reserves are hidden underground and most of our groundwater abstractions rates exceed groundwater renewing rates, leading to depletion. The growing demand and the expected climate change bring our groundwater reserves under mounting pressure. More than two-thirds of all abstracted groundwater is used for food production. Every year the world’s population is growing by 83 million people.

Improving our knowledge about how much water we can use in the near future while avoiding negative environmental and socio-economic impacts is therefore extremely important. A study like this contributes to the knowledge gap and can help guide towards sustainable water use worldwide to overcome potential political water conflicts and reduce potential socio-economic friction, as well as to secure future food production.

Want to read more? Check out the recent AGU press release or if you have more time… read my papers on dynamic water allocation (click here), development of a global groundwater model (click here, or here), or read my PhD thesis (here).



Author Inge de Graaf receiving her PhD degree from her advisor, professor Marc Bierkens (at Utrecht University, Netherlands). Note Tom Gleeson’s bald head in the lower left…

The great American groundwater road trip: Interstate 80 over the Ogallala Aquifer

The great American groundwater road trip: Interstate 80 over the Ogallala Aquifer




Authored by: Sam Zipper – Postdoctoral Researcher in the Department of Civil & Environmental Engineering at the University of Wisconsin-Madison


In late July, my wife and I loaded the dog into the car, cranked up the water-related tunes, and drove over a few million cubic meters of water. No, we haven’t traded in our sedan for an amphibious vehicle – rather, we were driving west, across Nebraska, on the Interstate 80 highway. While this may be a relatively boring road trip by conventional standards, it does provide an opportunity to drive across the famous Ogallala Aquifer, a part of the High Plains Aquifer system.


The wide reaching Ogallala Aquifer 1. The red line shows Interstate 80’s route.

While the geological history of the Ogallala is described in more detail elsewhere; the short version is that sediment, eroded off the Rocky Mountains over many millions of years, filled in ancient river channels, eventually creating the flat plains that characterize much of Nebraska today. Despite the flat landscape, however, the sights you’ll see along I-80 exist in their present form almost entirely due to this vast underground supply of water.


Irrigation

irrigation-sprinkler-large

A center-pivot irrigation sprinkler. A common sight over the Ogallala 2.

It’s estimated that upwards of 90% of the water withdrawn from the Ogallala is used for agricultural irrigation. Driving through western Nebraska, 90% seems like an underestimate. Center-pivot systems stretch away from the interstate as far as the eye can see, and it’s hard to imagine what this landscape would look like without the water from the Ogallala. While groundwater levels have declined in the most heavily irrigated parts of Nebraska compared to predevelopment conditions, they’ve fortunately stabilized over the past ~30 years; the most serious drawdowns are occurring further south, in Western Kansas, Oklahoma, and the Texas Panhandle.


The Mighty Platte

PlatteRiver

The mighty Platte River. Photo by Sam Zipper.

The Platte River stretches from the Rockies to its confluence with the Missouri River in eastern Nebraska, and I-80 follows the Platte through most of Nebraska. Along the way, the Platte is receiving water from surrounding groundwater systems.  This process of groundwater discharge to streams (often called baseflow), is particularly important for sustaining flow in the river during dry periods, along with the ecosystems, agriculture, and municipalities that depend on this water supply. For a more beautiful look at the Platte than my cell phone camera offers, check out the Platte Basin Timelapse project, which uses photography to explore the movement of water through the basin.


The Namesake


Ogallala Nature Park welcome sign. Photo by Sam Zipper.

The Ogallala is named after Ogallala, NE, a tiny town about a half hour’s drive from the Colorado border. The aquifer is named after Ogallala because that’s where the geologic “type locality” is – a fancy way of saying, they found the Ogallala formation here first. While we didn’t venture into the town of Ogallala itself, we did stop at the lovely Ogallala Nature Park just off the interstate for a stroll among the phreatophytic vegetation lining the banks of the Platte. Phreatophytes, such as the cottonwoods common to Nebraska, have evolved to have special roots which can extract water directly from groundwater when soil moisture supplies are low, thus allowing them to survive in the sandy, well-drained banks of the Platte.

Do you have any hydrogeologic highlights we should investigate on our drive back to Madison? Let me know via the comments below!


Picture Sources

https://upload.wikimedia.org/wikipedia/commons/thumb/4/44/Ogallala_saturated_thickness_1997-sattk97-v2.svg/2000px-Ogallala_saturated_thickness_1997-sattk97-v2.svg.png

http://water.usgs.gov/edu/pictures/full-size/irrigation-sprinkler-large.jpg


About the author:

Sam Zipper‘s research interests lie broadly at the intersection of humans and the environment, focusing on feedbacks between subsurface hydrology, vegetation dynamics, soil water retention characteristics, and climate & land use change that cut across the disciplines of hydrology and hydrogeology, soil science, agronomy, and ecology.  He is an ecohydrologist at the University of Wisconsin-Madison.


FloPy: A Python interface for MODFLOW that kicks tail!

FloPy: A Python interface for MODFLOW that kicks tail!

Authored by: Kevin Befus – Assistant professor, Department of Civil and Architectural Engineering at the University of Wyoming


Groundwater modeling is getting better. Models are becoming more sophisticated with simpler interfaces to add, extract, and process the data. So, at first appearances, the U.S. Geological Survey’s (USGS) recent release of a Python module named FloPy for preparing, running, and managing MODFLOW groundwater models seems to be a step backwards.

Oh, but it isn’t.

KB1

First, a couple disclaimers. Yes, at the time of writing this I work for the USGS and use this new Python module for my research. Did I have to use FloPy? No. Am I glad I did? YES! Before using FloPy, I dabbled in the various non-commercial MODFLOW interfaces but got bogged down on how many drop down menus, pop-up menus, wizards, and separate plotting programs with their own menus were needed to make a meaningful groundwater model on top of a new lexicon of variable names (IUPWCB must mean “internally unknown parameter with concentrated bacon”, right?).

FloPy made its official debut in February 2016 with a Groundwater methods report 1. Bakker et al. do an excellent job telling us why we should use FloPy. I’ll leave that to you and tell you what I think.

Here’s what is great about FloPy:

  1. FloPy is 100% MODFLOW. No tweaks to anything. You choose the executable file you want it to use or compile it yourself, and you’re off!
  2. You have the near-infinite data management, manipulation, and plotting capabilities of Python at your fingertips. Python has a lot of packages. It can be overwhelming. You can rely commercial packages like ESRI’s arcpy if you want, but there’s a list of free libraries that give you even more freedom to get the input data just right. Since I mentioned freedom, here’s the list of free libraries I find useful but it is in no way an endorsement nor exhaustive: scipy, numpy, gdal, osgeo, fiona, shapely, cartopy, pyshp, pandas, matplotlib, and let’s not forget…flopy!
  3. It’s easy to duplicate and alter an existing model. Once you have your script perfect for running a particular groundwater model, you can take pieces of it to make a slightly altered version, or you can pop it in a loop that runs through your uncertain inputs for sensitivity testing. Change your grid with the flip of a variable, and make sure that mesh converges!
  4. Loading other MODFLOW models works great. Say you want to run someone else’s model with slightly different recharge, but their recharge is variable in space. Since FloPy incorporates numpy’s grid/matrix handling capabilities, you can change individual entries with row-column selections or change the whole recharge grid by multiplying it by either a single number or say a random matrix with a normal distribution and some added noise. If you just want to use their recharge data to run your own model, you can save the position coordinates (they have hopefully provided you with their coordinate system and model transformations) and recharge arrays to your very favorite format (csv, nc, mat, tif) and load it later as a matrix to add to your model, all in a single Python script.
  5. Building off of the ability to load or create MODFLOW models, FloPy has functions for plotting 2D map or cross-section views of the model discretization, boundary conditions, and results. Shapefiles can be included in these plots if they are in the same coordinate system as the model or extracted from the model (ever want a polygon feature of every model cell with attributes for every property of that cell?). I do my own shapefile manipulations in Python, but FloPy has some great plotting tools built in.
  6. You already have the data in Python. See what adding a low permeability layer does to spring discharge. Then, with the model made, you have to make sense of it. Maybe develop some interesting spatial or time series analyses. Enter Python. Plotting with matplotlib also makes beautiful, journal article-worthy figures…with enough sweat and tears from your end (not as many as you may think). Yes, this is a repeat of 2), but, seriously, it’s in PYTHON!
  7. FloPy is totally free. Python is free. Tons of science-oriented libraries in Python are free.


Here’s a flashy example.  It is straightforward and only takes one script to create a SEAWAT model from scratch and plot the 2D steady state salinity distribution and flow vectors for a simple Henry 2 problem based on a slightly edited FloPy example script.  There are more than a dozen example scripts available on the FloPy site as well as a very cool capture ratio script provided in the methods report 1.

For the groundwater educators out there, a FloPy groundwater model script can be paired with homework questions that get students testing how changing hydraulic conductivity in certain parts of the model changes the water table configuration. Or maybe a new well needs to be drilled on a plot of land near a spring… The scenarios are endless. Students can develop a fundamental understanding of groundwater flow while getting experience with both groundwater modeling and computer programming. Win, win, and win.

Essentially all of the standard MODFLOW packages are operational in FloPy, and there are varying levels of support for some of the specialized MODFLOW compilations and processing tools (e.g., MODFLOW-USG, MODFLOW-NWT, MT3DMS, SEAWAT, PEST, and MODPATH). PEST and MODPATH are currently not executable with FloPy, but these features will probably be added in a future release (I have made my own klugy modules for running ZoneBudget and MODPATH that interface reasonably well with the rest of FloPy).

Get on your way and give FloPy a try today!


Links

The Python package is available online at https://github.com/modflowpy/flopy.

The documentation is available online at http://modflowpy.github.io/flopydoc/index.html.

The USGS FloPy page is http://water.usgs.gov/ogw/flopy/.


References

Bakker, M., V. Post, C. D. Langevin, J. D. Hughes, J. T. White, J. J. Starn, and M. N. Fienen (2016), Scripting MODFLOW Model Development Using Python and FloPy, Groundwater, doi:10.1111/gwat.12413.

Henry, H.R., 1964. Effects of dispersion on salt encroachment in coastal aquifers. In: Cooper, H.H. (Ed.), Sea Water in Coastal Aquifers: U.S. Geological Survey Water- Supply Paper 1613-C p. C71–C84.


About the author:

Kevin Befus is a groundwater hydrologist with geology and geophysics experience — examining geological, biological, and chemical processes, especially considering their connections to water across scales.

KB3

Follow

Get every new post on this blog delivered to your Inbox.

Join other followers:
