Image of the Week – A rather splendid round-up of CryoEGU!

Image of the Week – A rather splendid round-up of CryoEGU!

The 2017 edition of the EGU general assembly was a great success overall and for the cryospheric division in particular. We were for instance thrilled to see that two of the three winning photos of the EGU Photo contest featured ice! To mark the occasion we are delighted to use as our image of this week,  one of these pictures, which  shows an impressive rapid in the Pite River in northern Sweden. Congratulations to Michael Grund for capturing this stunning shot.  You can find all photos entered in the contest on imaggeo — the EGU’s  open access geosciences image repository.

But being the most photogenic division (at least the ice itself is…not sure about the division team itself!) was not our only cryo-achievement during the conference. Read on to get the most of (cryo)EGU 2017!


EGU 2017 in figures

  • 17,399 abstracts in the programme (including 1179 to cryo-related sessions)
  • 14,496 scientists from 107 countries attending the conference
  • 11,312 poster, 4,849 oral and 1,238 PICO presentations
  • 649 scientific sessions and 88 short courses
  • 53% of early-career scientists

Polar Science Career Panel

During the week we teamed up with APECS to put on a Polar Science Career Panel. Our five panellists, from different backgrounds and job fields, engaged in a lively discussion with over 50 session attendees. With many key topics being frankly and honesty discussed by our panelists, who had some great comments and advice to offer. Highlights of the discussion can be found on the @EGU_CR twitter feed with #CareerPanel.

At the end we asked each panellist to come up with some final words of advice for early-career scientists, which were:

  • There is no right and wrong, ask other people and see what you like
  • Remember you can shape your own job
  • Take chances! Even if you are likely to fail and think outside the box
  • Remember that you are a whole human being… not only a scientist and use all your skills
  • And last but not least… come and work at Carbon Brief (thanks Robert McSweeney!!)

However, the most memorable quotation of the entire panel is arguably from Kerim Nisancioglu :

Social media

One of the things the EGU Cryosphere team has been recognised for is its great social media presence. We tweeted away pre-EGU with plenty of advice, tips and information about events during the week and also made sure to keep our followers up-to-date during the week.
If it is not yet the case, please consider following us on twitter and/or facebook to keep updated with the latest news about the cryosphere division, the EGU or any other interesting cryo-related news!

We need YOU for the EGU cryosphere division

Conferences are usually a great way to meet new people but did you know that getting involved with the outreach activities of the division is another way?

Each division has an ECS (early-career scientist) representative and a team to go with that and the Cryosphere division is one of the most active. Our new team of early-career scientists for 2017/18 includes some well known faces and some who are new to the division this year:

Nanna Karlsson : outgoing ECS representative and incoming coordinator for posters and PICOs awards

Emma Smith : incoming ECS representative and outgoing co-chief editor of the  cryoblog

Sophie Berger: chief-editor of the cryoblog and incoming outreach officer

Clara Burgard : incoming co-chief editor the cryoblog







We also have many more people (who aren’t named above) involved in the blog and social media team AND the good news is that we are looking for new people to either run our social media accounts and/or contribute regularly to this “award winning” cryoblog. Please get in touch with Emma Smith (ECS Representative and former blog editor) or Sophie Berger (Chief Blog Editor and Outreach Officer) if you would like to get involved in any aspect of the EGU Cryosphere team. No experience is necessary just enthusiasm and a love of bad puns!

And here is your “Save the Date” for EGU 2018 – which will be held between 8th – 13th April 2018.

Co-authored by Emma Smith and Sophie Berger

A brief guide to navigating EGU 2017!

A brief guide to navigating EGU 2017!

Are you going to the EGU General Assembly in Vienna next week? If so, read on for a quick guide to navigating the week: Where to start, what to see and how to meet people and enjoy yourself! After all, the meeting is as much about the opportunities meet scientists from all over the world as it is about the science itself.


How on Earth do I know what is going on?!

The EGU General Assembly is a massive meeting with many parallel session, short courses, medal lectures and much more. So how do you know what is going on and when, and how can you effectively keep track of it all? The simplest way is to use the online EGU program – it has options to browse sessions of interest chronologically or by discipline. You can simply click on a session or an individual presentation to add it to your personal programme. You can then view your personal program online, print it as a PDF or if you have a smartphone you can also use the EGU2017 mobile app to keep track of your personal program on the go – scan the QR code to download it or click here from your smartphone.

Don’t forget to keep track of the twitter hastag #EGU17 to see what is happening on a second by second basis and also the #CryoEGU17 hashtag for up-to-date cryosphere news.


Short courses

Short courses at EGU are designed to give you an insight into a certain area or topic and cover all sorts of subjects and skills. There are many courses running at EGU this year – we have highlighted a few below, but be sure to check out the full list in the online program. Short courses provide a great chance to learn about a topic, skill or piece of software that has been on your to do list, so why not drop by and meet the experts who have kindly agreed to participate and share their knowledge?

How to navigate EGU: tips & tricks

When and Where: Mon, 24 Apr, 08:30–10:00,  Room -2.31

Held first thing on Monday morning, this could be just the session you need to get your week off to a productive start!

Quantarctica

When and Where: Mon, 24 Apr, 13:30–15:00, Room -2.31

Are you working on Antarctica data and getting to grips with GIS? Then this course is for you! The User Workshop is aimed at beginning and intermediate GIS users and Antarctic researchers interested in learning how to integrate, analyze, and present their own research data with the free, open-source, cross-platform QGIS software. Participants should install and test the latest version of the Quantarctica package on their laptops prior to arriving at the workshop.

Crashing the Cryosphere

When and Where: Mon, 24 Apr, 15:30–17:00, Room -2.16

This is one to tell your cryo-curious friends from other divisions about!  We are inviting scientists from all areas to join us in “gate-crashing” the Cryosphere Division and learn about how topics in cryospheric science are relevant to their research. During the short course, four cryosphere experts will introduce their research, giving you the background to venture further into cryospheric topics during the rest of the meeting.

  • Keynote Intro: Olaf Eisen (The AWI, DE and head of EGU Cryosphere Division)
  • Ice-Ocean interaction: Inga Koszalka (GEOMAR, Kiel, DE)
  • The Arctic Atmosphere : John Prytherch (MISU, Stockholm, SE)
  • Avalanches: Thierry Faug (Irstea, FR)
  • GIA/Solid Earth: Valentina Barletta (DTU, DK)

Communicating Climate Change – blogging as a group

When and Where: Wed, 26 Apr, 13:30–15:00, Room -2.85

Blogs are a great way to communicate your science, but where do you start? This interactive short course will begin with an introduction from Mathew Reeve, founder of ClimateSnack. It will then be over to you to get some practice experience at editing a blog post – turning an awful draft into a pleasant and clear blog post. Please bring a pen and paper.

Successful strategies to design, develop and write a scientific paper

When and Where: Wed, 26 Apr, 17:30–19:00, Room N2

An essential part of a career in research is publishing papers in peer-reviewed journals. This means responding to reviews of your own work and reviewing the work of other scientists. In this short course you will get the chance to learn how to navigate the review process. The course will start with some advice, tip and tricks from Benjamin Rabe (Researcher, AWI, Germany), Julienne Stroeve (Senior Research Scientist, NSIDC, USA), Tom Coulthard (Professor of Physical Geography, University of Hull, UK) and Paul Cumine (Publisher, Geophysics and Oil & Gas Journals, Elsevier Ltd., UK) before a panel discussion to allow you to get answers to those burning questions you may have!

Polar Science Career Panel (EGU Cryosphere and APECS)

When and Where: Thu, 27 Apr, 15:30–17:00, Room -2.16

Many early career scientists come to EGU looking for inspiration to take the next step in their careers. There are so many opportunities both academic and elsewhere that it can be daunting to know where to start looking and what the options are. Join us for a panel discussion about everything to do with life post-polar-PhD and expand your ideas about where you might go next. Our panelists are:

  • Felicity Liggins (Climate Scientist and Outreach Program Manager, Met Office, UK)
  • Robert McSweeney (Science Writer, Carbon Brief)
  • Lindsey Nicholson (PostDoc, Uni. Innsbruck, Austria)
  • Kerim Nisancioglu (Prof. Of Earth Sciences, Uni. Bergen, Norway)
  • Wiebke Schubotz (Project Coordinator of HD(CP)², Max Planck Institute for Meteorology, Germany)


Social event for Early Career Cryosphere Scientists!

So you have an idea of what scientific stuff is going on, but there is, of course, another important aspect to any conference…. they are a great place to socialise! However, it can be very daunting to know how and where to meet people at such a large meeting. This year the EGU Cryosphere team are organising two social events joint with APECS as well as a lunch for anyone who is interested in joining our blog team – also don’t forget the March for Science taking place on Saturday the 22nd April.

Pre-Icebreaker Meet Up

The conference icebreaker can be a daunting experience to attend alone but it is a great event to go along to. We are organising a friendly pre-icebreaker meet up for cryospheric ECSs on Sunday 23rd from 16:00We will meet at a yet-to-be-determined cafe in Vienna, have a chat, do some networking, have a cake and then head to the EGU conference centre together in time for the icebreaker. Keep your eyes on the Facebook event for more details!

Cryo Night Out!

On Thursday evening (27th), after the Polar Science Career Panel there will be a joint APECS and EGU Cryosphere division night out. We will be leaving from the conference centre after the panel session (Room -2.16) and heading for Wieden Braü for food and drinks, you can walk down with us as a group or meet there at 19:30. If you would like to eat please fill out the Facebook poll to give us an idea of numbers! Hopefully see plenty of faces old and new there 😀

EGU Cryosphere Bloggers Lunch

An informal lunch meeting for anyone interested in getting involved in the EGU Cryosphere blog on Tuesday 25th. Meet in front of the main entrance at 12:15 and we will decide on where to go depending on the weather. Please email the editors Emma (emma.smith@awi.de) or Sophie (sberger@ulb.ac.be) if you want to come along but aren’t sure who to look for. As an extra incentive Sophie will be bringing some Belgian chocolate!!

Ice Core Young Scientist (ICYS) social

Early-career scientists with an interest in ice cores are invited to join the Ice Core Young Scientists (ICYS) for a get-together with drinks and/or dinner on Tuesday 25th, from 18:30 (more details on facebook).
The get-together will take place at Café Einstein, Rathausplatz 4, Vienna . For those going directly from the conference venue, we will be leaving from there at 17:45, and you can find us (Mai Winstrup & Emma Kahle) by the main entrance.

March for Science

The day before the official start of the EGU GA (Saturday 22nd April) is Earth Day. On this day scientists and science enthusiasts across the globe will be marching to celebrate science and to call for the safeguarding of its future. A satellite march organised by local researchers is taking place in Vienna. If you are going to be in Vienna on the Saturday then it is a great chance to get involved – find out more details, including where and when to meet, on the EGU blog.


Am I an ECS?

The EGU officially defines an Early Career Scientist (ECS) as:

an undergraduate or postgraduate (Masters/PhD) student or a scientist who has received his or her highest degree (BSc, MSc, or PhD) within the past seven years  (where appropriate, up to one year of parental leave time may be added per child).

However, everyone is of course more than welcome to come along and  attend the short courses and social events organised by your ECS team, the more the merrier!


General Advice….

The General Assembly can be an overwhelming experience. Here are some tips from the EGU Cryosphere’s esteemed ECS representative Nanna Karlsson:

  • Take advantage of the lunch breaks and go for a walk! When you exit the main conference building turn left and head for the river, or turn right and you will find that behind the concrete buildings there is a very nice park.
  • Go to a session outside your field or area of interest. Even in completely different research topics, I often find similarities in methods or applications that inspire me to think differently about my own research.
  • Explore Vienna and treat yourself to a bit of time off to recover during the week. If your programme is completely packed, then hurry to the U-Bahn in a lunch break (the ticket is after all included in the registration fee) and go to the centre of town. Half an hour’s stroll will give you at least an impression of the city and you will not leave Vienna with the feeling that you have really only seen the conference centre.

Edited by Nanna Karlsson

Image of the Week — FRISP 2016

Image of the Week — FRISP 2016

The Forum for Research into Ice Shelf Processes, aka FRISP, is an international meeting bringing together glaciologists and oceanographers. There are no parallel sessions; everyone attends everyone else’s talk and comment on their results, and the numerous breaks and long dinners encourage new and interdisciplinary collaborations. In fact, each year, a few presentations are the result of a previous year’s question!

The location changes every year, moving around the institutions that are involved with Arctic and Antarctic research. The 2016 edition just occurred this week, 3rd – 6th October, in a marine research station of the University of Gothenburg, in the beautiful Gullmarn Fjord.

Each year, a few presentations are the result of a previous year’s question!

Fjord at the sunset [Credit: Céline Heuzé]

Gullmarn fjord at the sunset [Credit: Céline Heuzé]

70 participants from 37 institutions:

  • Attended 49 talks on model results, new observation techniques, and everything in between;

  • Spent more than 15h discussing these results, including 2h around 15 posters;

  • Drank 50 L of coffee, 60 L of tea, 20 L of lingon juice… and a fair amount of wine!

Poster session at the FRISP 2016 meeting. [Credit: Céline Heuzé]

Poster session at the FRISP 2016 meeting. [Credit: Céline Heuzé]

I can’t really choose THE highlight of the conference.
As an organiser, it was a real pleasure to simply see it happen after all the long hours of planning.
As a scientist, it was a great and productive meeting, giving me new ideas and the opportunity to discuss my recent work with the big names of the field in a friendly environment.
And as a human, I enjoyed most the under-ice footages, and in particular the general ”ooooh” that came from the audience.

It was a bit sad to say goodbye to the participants, old friends and new collaborators. But I know that I will see them again during FRISP 2017… and I hope to see you there as well!

 Edited by Sophie Berger and Emma Smith

Image of the Week — Where do people stay in the “coolest” place on earth?

Image of the Week — Where do people stay in the “coolest” place on earth?

What word would you use to characterise the Antarctic ?

White?
Windy?
Remote?
Empty?
Inhospitable?
Wild?
Preserved?

While all of these are true it may surprise you to find out that the Antarctic is occupied by humans all year round with almost half of its 82 research stations operating 365.25 days a year!

Just a few hours before the launch of the biennial Antarctic meeting held by the Science Committee on Antarctic Research (SCAR) in Malaysia, we thought it would be perfect timing to check out who is leading research in Antarctica and where…

…but before that let’s have a look first at what makes Antarctica so special!


Antarctica, a very peculiar continent, regulated by the Antarctic treaty

Antarctica is regulated by the Antarctic Treaty that defines this continent as a “natural reserve, devoted to peace and science” (Environmental Protocol, 1991). This means that since the treaty came into force in 1961:

  • the Antarctic environment is fully protected
  • the land doesn’t not belong to any country because the treaty pauses existing territorial claims in Antarctica, as long as it stays in force
  • Antarctica has been demilitarised and no nuclear tests are allowed
  • International collaboration in the name of progressing scientific research is encouraged, with many countries with greater operational capacity aiding those with little or none to allow them to conduct research.

Who is conducting research in Antarctica and where?

Mc Murdo Station on Ross Island (West Antarctica). The station is operated by the US Antarctic Program and can accommodate up to 1,000 people. [Credit: Gaelen Marsden on Wikimedia Commons]

Mc Murdo Station on Ross Island (West Antarctica). The station is operated by the US Antarctic Program and can accommodate up to 1,000 people. [Credit: Gaelen Marsden on Wikimedia Commons]

The map above shows the 82 permanent research stations dotted across the Antarctic. Among those bases, 40 are operated all year long while the others only host scientific research during the Austral summer (November-February). The location and capacity of these stations also varies considerably from one to another. For instance, the US McMurdo station – the biggest scientific base in Antarctica – is settled on an island and is open all year-ong, accommodating up to 1,000 people during summer. On the contrary, a small seasonal station such as the Belgian Princess Elisabeth Station is only open during the summer and can host up to 20 people.

Princess Elisabeth Station, (Dronning Maud Land, East Antarctica). This seasonal station is located hundred of kilometers from the

The Belgian Princess Elisabeth Station, (Dronning Maud Land, East Antarctica). This station is only open during the austral summer and is located hundreds of kilometres away from from the coast. [Credit: René rober – International Polar Foundation]

The research supported by these scientific stations is very broad and covers topic as diverse as sea level rise, climate change, observation of space, biodiversity, etc… Much of this happens in the austral summer when field parties are able to travel from the research stations into even more remote areas of the continent to conduct experiments and install equipment. However, some science, such as meteorology and weather observations takes place all year round no matter how cold, windy and inhospitable the continent may be for those conducting the research.

This is the case of the two “brave” GPSes of Tweetin ice shelf project, which are installed on an ice shelf and tweet their position and movement all year long (you can follow them on @TweetinIceShelf).

Antarctic (stations) fun facts

  •  1 is the number of station operated by an African country : SANAE IV (South Africa)
  • 13 stations is the maximum for one single country (Argentina)
  • -89.2°C is the coldest temperature ever recorded on earth. It was at an Antarctic Station:  Vostok (Russia)
  • 1904 is the opening date of the oldest station still in activity: Orcadas (Argentina)
  • 2014 is the opening date of the youngest station : Jang Bogo (Republic of Korea)
  • 1,000 people is the maximum number of people that a station can accommodate : Mc Murdo (USA)
  • 4087 m is the elevation of the highest station : Kulun (China)
  • 8 is the number of Pokemon Go currently pinpointed in the Antarctic 😀

Here are the countries with at least one scientific base in Antarctica, does yours belong to this list?

Countries with at least one research station in Antarctica, the colors correspond to the colors of the Antarctic stations in the map above [Credit: adapted by Sophie Berger from Wikimedia Commons LINK: https://en.wikipedia.org/wiki/File:Antarctican_bases.png]

Countries with at least one research station in Antarctica, the colours correspond to the colours of the Antarctic stations in the map above [Credit: adapted by Sophie Berger from Wikimedia Commons]

Previous blog posts about Antarctic fieldtrip

Edited by Emma Smith

European Space Agency Living Planet Symposium 2016

European Space Agency Living Planet Symposium 2016

Living Planet Symposium

Between the 9th and 13th May, Prague played host to the European Space Agency’s (ESA) fourth Living Planet Symposium. The event, the largest in its history with over 3300 attendees, brought together the earth observation community across multiple disciplines to discuss significant scientific results and the future developments of earth observation missions. Earth Observation  of the Cryosphere over the last few decades has revolutionised our understanding of these regions, allowing us to monitor and assess ice sheet dynamics at unprecedented spatial and temporal scales.

ESA & Observation of the Cryosphere

The role of Earth Observation in Cryospheric sciences is set to increase further thanks to the European Commission and ESA Copernicus program; a series of satellites called Sentinels which all feature different sensor instrumentation, allowing researchers to monitor various aspects of the Earth System. The program will consist of 6 separate sentinel missions and will allow us to measure various Ice Sheet and Glacier dynamics continuously at a high temporal resolution. In addition, the Earth Explorer mission CryoSat-2 has been transforming our knowledge of the polar regions since it’s launch in 2010.

As a result, the conference had a wide range of exciting scientific results related to the Cryosphere from these missions; ranging from data products to be used by the community to the exploitation of mission data to further our knowledge of key processes and outstanding scientific questions.

Don’t worry if you weren’t able to make the symposium, as this post will highlight a selection of interesting results and the impact they will have on Cryospheric research!

CryoSat-2: Transforming Knowledge of the Cryosphere

CryoSat-2, an ESA Earth Explorer satellite that carries onboard a radar altimeter to measure ice elevation (Credit : ESA – P. Carril)

CryoSat-2, an ESA Earth Explorer satellite that carries onboard a radar altimeter to measure ice elevation (Credit : ESA – P. Carril)

CryoSat-2 is the ESA Earth Explorer radar altimetry mission dedicated to monitoring changes in surface elevation of earth’s ice sheets, sea-ice thickness and extent; which it has been routinely monitoring since November 2010. The combination of its unique polar orbital characteristics and novel dual antenna interferometric mode of operation has allowed it to overcome  many of the issues associated with previous altimetry missions over ice sheets.

Major results from CryoSat-2 included the application of swath processing techniques to the interferometric data to dramatically increase the number of surface elevation measurements available to researchers (Gray et al, 2013). Traditionally, the radar instrumentation would record a single elevation measurement at the point of closest approach (POCA) to the satellite. However, this technique analyses the whole radar return to produce measurements across the satellite footprint. By exploiting this increased data density it allows researchers to investigate ice sheet changes at much finer spatial and temporal resolution, allowing for an increase in the range of scientific questions the satellite is able to address. Examples of this include glacier thinning as a result of surging events that have previously occurred on time scales not possible to be captured by the satellite. It will also allow us to get a more complete picture of mass balance using the altimetry method.

Ice-shelf thickness in Antarctica

Furthermore, a contemporary continental ice shelf thickness dataset (Chuter and Bamber, 2015) derived from CryoSat-2 was presented; which provides large accuracy improvements over the previous ERS-1 derived dataset (Griggs and Bamber, 2011), particularly in the grounding zone, a key region for monitoring ice sheet stability. The results from this work will allow the community to improve accuracy in mass balance estimations from the input-output method, sub-ice shelf ocean modelling and for parameterisations in ice sheet models.

Ish_thick

Antarctic ice shelf thickness Derived from CryoSat-2 radar altimetry (Credit: subset of fig S1 from Chuter and Bamber, 2015).

Monitoring sea ice

Sea ice monitoring is also a key mission objective, with the satellite already delivering on these aims through studies of continuous monitoring of the Arctic Sea Ice over the past five years.  Work presented at the symposium by Rachel Tilling (CPOM/University College London) makes use of the Near Real Time data products from ESA to deliver knowledge of sea ice thickness and extent as quick as two days after data acquisition, providing benefits to the shipping industry in addition to aiding arctic climate predictions (see also Tilling et al, 2015).

Antarctic mass balance

For the Antarctic ice sheet, mass balance estimates obtained from altimetry, gravimetry, and mass-budget methods can yield conflicting results with error bars that do not always overlap.

Some of these techniques use models to isolate and remove the effects of glacio-isostatic adjustment and surface mass balance (SMB) processes,  introducing another source of uncertainty which is hard to quantify.

a) Estimates of mass balance for the Amundsen Sea Embayment (ASE) sector in Antarctica from different techniques, including estimates from the RATES project. b) Estimates of the mass loss due to ice dynamics (red) and SMB (blue) for the ASE, compared with modeled values from RACMO2.3 (red dots) and ice discharge (blue line) (Credit: fig 9a from Martín-Español, et al. 2016)

a) Estimates of mass balance for the Amundsen Sea Embayment sector in West Antarctica from different techniques, including estimates from the RATES project. [IOM = Input-Output Method] b) Estimates of the mass loss due to ice dynamics (red) and Surface Mass Balance (SMB — blue) for the Amundsen Sea Sector, compared with modeled values from RACMO2.3 (red dots) and ice discharge (D — blue line) (Credit: fig 9 from Martín-Español et al. 2016)

To address both these issues, the RATES project presented a statistical modelling approach to the problem (Martin-Español et al., 2016). They combined the observational data (including satellite altimetry, GRACE, GPS and InSAR), and used prior information to separate out the mass balance signal into its main components.  For instance, we know that the glacio-isostatic adjustment has a large spatial length-scale, but  changes in ice dynamics may vary from one glacier to the next. We thus can `look’ for these components within the data and attribute them to the correct process. For the period 2003-2013, they estimated a mean mass balance rate of -82±23 Gt/yr with a sustained negative mean trend of dynamic imbalance to which West Antarctica is the largest contributor, mainly triggered by high thinning rates of glaciers draining into the Amundsen Sea Embayment. The Antarctic Peninsula has experienced a dramatic increase in mass loss in the last decade following the destabilization of the Southern Antarctic Peninsula. The total mass loss is partly compensated by a significant mass gain in East Antarctica due to a positive trend of SMB anomalies.

4th Cryosat User workshop

In addition to major scientific results and products, the conference combined with the 4th CryoSat User Workshop, bringing together users from all cryospheric disciplines to discuss a variety of issues such as: Product Calibration and Validation campaigns, future data product releases and further serving the needs of the scientific community. In addition, with the satellite currently being operated beyond in it’s initial commissioning timespan, initial discussions were held regarding whether there would be the possibility of a follow up and the form it could possibly take.

Sentinel 1A/B – A New Era for Ice sheet Velocity Mapping

sentinel

Sentinel 1A/B is the Copernicus Synthetic Aperture Radar (SAR) mission, providing global radar imagery currently at a 12 day repeat period, free from the limitations posed by multispectral imagery such as cloud cover. The launch of Sentinel 1B on the 25th April this year to join in constellation with 1A will reduce this repeat period to 6 days. This will allow for continuous, long term monitoring of the Earth’s Cryosphere at a high temporal resolution.

Sentinel 1 results presented at the conference exemplified the transformative power this mission will have on Cryospheric sciences. Firstly, it will allow us to produce continental velocity maps for both Greenland and Antarctica at sub-annual resolution. This will allow for monitoring of seasonal velocity changes in outlet glaciers, better estimations of mass balance and improved parameterisations of conditions in ice sheet models.  Additionally, the mission is now providing researchers with a near real time data stream of ice velocities for key outlets of the Greenland and Antarctic ice sheets, allowing them to track changes and investigate changes in behaviour at 12-day scale (reducing to 6 days with 1B) (Hogg et al, 2016).

Ice Sheet velocity across the Antarctic peninsula derived from Sentinel 1 data from December 2014 to March 2016. Image Credit ESA and ENVEO: http://www.esa.int/spaceinimages/Images/2016/05/Antarctic_Peninsula_ice_flow

Ice Sheet velocity across the Antarctic peninsula derived from Sentinel 1 data from December 2014 to March 2016. (Credit: ESA and ENVEO)

The grounding line is a key region of the ice sheet to monitor due to it’s ability to indicate changes in the dynamics of the inland Ice Sheet and it’s potential instability. SAR missions allow us to map the grounding line with high accuracy by analysing the differences in vertical tidal displacement of the ice shelves between images via the formation of interferograms. Previously there has been discontinuous temporal coverage from various SAR missions; however with the advent of Sentinel 1 mission, it will possibly to routinely monitor grounding line flux position for an extended period of time, improving our understanding of key ice sheet processes and inland grounded ice stability.

Final Thoughts

The conference showed us the combined power offered by the new Sentinel missions and the continuation of CryoSat-2 in allowing us to monitor the Cryosphere at scales not previously possible, thus shedding more light on the dynamics of these key earth system regions. The new satellites have allowed researchers to produce new and improved datasets open for use by the scientific community, helping to accelerate and enable future discoveries. Additionally, when these datasets are used in combination, they can help us to better answer some of the subject’s biggest questions; such as the mass balance of the Ice Sheets and its changes over time. As a result, these missions promise for exciting times ahead in terms of greatly forwarding our understanding of the Cryosphere.

 With the new sentinel missions and the continuation of CryoSat-2 exciting times are ahead for remote sensers of the cryosphere

Aside from the Conference – City of Prague

Prague offered many sights and opportunities to explore during the downtime of the conference. Highlights of the City included the Charles Bridge built in 1390 and the old Town Square which hosts the famous astronomical clock. All of this is set to the backdrop of Prague Castle, the largest ancient castle in the world and residence of the President of the Czech Republic. The City also has a famous classical music and opera scene and offers some of the world’s best beer, providing the perfect opportunity to network and make contacts!


References

  • Chuter, S. J., and J. L. Bamber (2015), Antarctic ice shelf thickness from CryoSat-2 radar altimetry, Geophys. Res. Lett., 42(24), 10,721–10,729, doi:10.1002/2015GL066515.
  • Gray, L, D Burgess, L Copland, R Cullen, N Galin, R Hawley, and V Helm. 2013. “Interferometric Swath Processing of Cryosat Data for Glacial Ice Topography.” The Cryosphere 7 (6). Copernicus GmbH: 1857–67.
  • Griggs, J.A., and J.L. Bamber. 2011. “Antarctic Ice-Shelf Thickness from Satellite Radar Altimetry.” Journal of Glaciology 57 (203). International Glaciological Society: 485–98. doi:10.3189/002214311796905659.
  • Hogg, A., A. Shepherd, N. Gourmelen (2015) A first look at the performance of Sentinel-1 over the West Antarctic Ice Sheet, FRINGE 2015, Frascati, Italy, 23-27 March 2015.
  • Martín-Español, A. et al. (2016), Spatial and temporal Antarctic Ice Sheet mass trends, glacio-isostatic adjustment and surface processes from a joint inversion of satellite altimeter, gravity and GPS data, J. Geophys. Res. Earth Surf., 120, 1–18, doi:10.1002/2015JF003550.
  • Tilling, R. L., A. Ridout, A. Shepherd, and D. J. Wingham (2015), Increased Arctic sea ice volume after anomalously low melting in 2013 – supplementary Information, Nat. Geosci., 8(8), 643–646, doi:10.1038/ngeo2489.

Edited by Sophie Berger


steve

Stephen Chuter is a PhD Student at the University of Bristol, UK. He  Investigates the dynamics of the Antarctic Ice Shelves and grounding zone using the ESA CryoSat-2 satellite. The unique orbital characteristics and novel SARIn mode of operation allow us to study these areas in much greater detail than possible from previous radar altimetry missions, therefore allowing us to greater ascertain its role in ice sheet stability. He tweets as @StephenChuter.
Contact Email: s.chuter@bristol.ac.uk



From Hot to Cold – Volcanology Meets the Cryosphere

From Hot to Cold – Volcanology Meets the Cryosphere

Hello again, I’m Kathi Unglert, and you’re about to read my third and final post as a student reporter at EGU 2016. Today I am writing about my experience in the cryosphere sessions from my volcanology perspective.


In preparation for the conference I kept thinking about what sort of research I would see in the cryosphere sessions. I had never really attended any specific conferences or meetings on the topic, so most of what I knew was from work that friends of mine do, which is mainly ice stream modelling. I am wondering whether similar tools (for example, analytical or numerical methods) can be used to model ice streams and lava flows?



A Tale of Ice and Fire

Thinking about the differences between ice streams/glaciers and lava, another potential overlap between cryospheric sciences and volcanology jumps out; In places like Iceland, volcanoes sometimes sit underneath large ice sheets. Similarly, tall volcanoes – particularly those in high mountain ranges – are often covered in snow and have small glaciers in their craters or on their summits. It is important to understand the interactions between the warm volcano, the hot lava, and the cold ice. For example, to forecast catastrophic floods that often occur when a subglacial volcanic eruption melts parts of the overlying ice and snow (so-called “jökulhlaups”). There is even a commission on “glaciovolcanism”, and it turns out that astrogeologists are quite interested in the topic to learn more about potential volcano-ice interactions on Mars. I had no idea how interdisciplinary this field of research was. It would definitely be useful for volcanologists to poke their heads into cryosphere meetings once in a while, and vice versa. Throw a little bit of planetary science in the mix, and you have a textbook example of interdisciplinary research!

Lava meets snow: Lava flowing into a canyon at the snow covered Eyjafjallajökull during an eruption in 2010 - one of the many examples where volcanology and cryospheric sciences meet. Photo credit: Martin Hensch (Imaggeo)

Lava meets snow: Lava flowing into a canyon at the snow covered Eyjafjallajökull during an eruption in 2010 – one of the many examples where volcanology and cryospheric sciences meet. Photo credit: Martin Hensch (Imaggeo)

The methods that we use in the different fields can also be quite similar: Resistivity measurements can be used to determine the extent of permafrost in the subsurface in Artic regions, but also to detect high temperature bodies beneath volcanic edifices that may be storing magma. I also saw a PICO presentation at the conference last week that uses cosmic rays to image the bed of a glacier in the Swiss Alps, a technique that volcanologists have tested to detect magma reservoirs and conduits on volcanoes!

In terms of the bigger picture, volcanological and cryospheric research overlap a lot in climatology. Erupting volcanoes emit gases and increase aerosols in the atmosphere, which can affect the climate locally, regionally, or even globally. The traces of such volcanic eruptions can sometimes be found in ice cores, where volcanic ash gets trapped and preserved for centuries or more. For a long time, it has been known that at least one big volcanic eruption in the 6th century – the traces of which have been found in ice cores – caused strong changes in climate for a few years, and some studies suggest that these effects may have contributed to political and societal instability in the Maya civilization in Central America at the same time. There was even a press conference about it at the EGU 2016 meeting. Other questions that we could ask might be “Does wide spread glaciation change the frequency or nature of volcanic eruptions?”, “How do volcanic eruptions affect the climate and ice stream or glacier dynamics?”, or “What can we learn about glacier dynamics by analyzing the locations of volcanic deposits in ice?”

So you know how they say “go big or go home”? Let’s put our minds together and get interdisciplinary! At the very least it’s going to be fun to think in slightly different terms for a while, and who knows where it may lead!



The EGU Student Reporter Experience

All in all, it’s been really great taking part in the Student Reporter Programme, and peeking into a totally different field. Seeing overlap between the different disciplines was a good experience, and one that was made possible by being a student reporter. Sometimes we get so stuck in our individual little niche that there is no room for anything else, despite the fact that other disciplines might have come across the same problems, struggled with the same methods, and maybe found a solution. I was lucky that the session schedule worked out ok – most days when things were a bit slow volcanology-wise I was able to go a cryosphere session. However, that way it was a very busy week, there was rarely ever any downtime, or time away from the conference. During the few quiet moments I spent time in the press office, doing some background research for my posts, editing work from the other reporters, or going to a press conference. I have to say, the press office was a new, but very cool experience. There were always interesting people around, both scientists presenting their latest results and journalists trying to find a new story. I’ve been into science writing for a while, so meeting some of the people whose work I read was a really cool bonus to the whole programme! If you enjoy writing, don’t mind a faster pace, and are curious about science at EGU outside your field I would highly recommend the Student Reporter Programme. If there is no blog in your discipline (like it was the case for me) that might even be a good thing, and you’ll get to learn some new and unexpected things!

(Edited by Emma Smith and Sophie Berger)




profile_highres_EarthMatters_lightKathi Unglert is a PhD student in volcanology at the University of British Columbia, Vancouver. Her work looks at volcanic tremor, a special type of earthquake that tends to happen just before or during volcanic eruptions. She uses pattern recognition algorithms to compare tremor from many volcanoes to identify systematic similarities or differences. This comparison may help to determine the mechanisms causing this type earthquake, and could contribute to improved eruption forecasting. You can find her on Twitter (@volcanokathi) or read her volcano blog.



The art of surviving a week of conferencing

The art of surviving a week of conferencing

Hello everyone! My name is Kathi Unglert and I’m a PhD student in volcanology at the University of British Columbia in Vancouver. I will be reporting for the Cryospheric Sciences blog during the upcoming EGU General Assembly as part of the “Student Reporter Programme”. With the meeting only a few days away, I thought I’d put together a quick guide how to make the most out of a whole week of conferencing. Hopefully you’ll find it useful! So here we go:

Preparation

Usually I would tell you to start your conference preparation way before the conference. Many conferences have a short course/field trip/professional development program around the actual conference dates. These things fill up fast, so look at the program and decide what you want to do early on (and sign up!). Often these events have discounts if you sign up early, so that’s another bonus. However, given that it’s only 3 days before the meeting starts I guess we’ll skip this step. So here’s what’s next:

Decide on a theme

Conferences are really bad for people like me, who sometimes try to do everything. There are so many opportunities and interesting things going that it’s usually impossible to take advantage of everything. The first step can be to choose a few sessions and sit all the way through them, instead of picking individual talks. You avoid running around trying to find rooms at the last minute, missing half of the talk you really wanted to see because the previous one in a different room ran late, and often the talks with the least appealing titles turn out to be the best. It can also help to identify a theme for the conference. For example for this EGU General Assembly my theme will be – you guessed it – science communication! I will leave my usual field (volcanology) and try out the mostly unknown, cold waters of cryospheric sciences. I am hoping to learn lots of new concepts that may apply to my own field. I will also do my best to view everything from a reporter’s perspective and relay anything I deem cool or fun or important to you! I might try to get into a few press conferences, and go to some of the “Meet the Editor” meetings. So much to do! Of course your “theme decision” doesn’t mean that you can’t do anything outside of the theme, it just helps to focus your attention and time. Need some inspiration to decide on your theme for EGU? Why not check out this early career guide, or some of the short courses!

Do some pre-conference research

There might be a person attending the conference with exactly the kind of job you could see yourself in. Or the researcher who came up with this awesome method that you’ve been using already, but that you still have some questions about. Or your friend from your undergrad who now lives on a different continent and whom you haven’t seen in 3 years. There are lots of reasons to look at the conference program ahead of time. When you see somebody in the program that you would like to meet, get in touch with them before the conference, and maybe you can arrange a meeting over a coffee, in a specific session, or over dinner (see Have fun).

Check for volunteering options

Some conferences give students the opportunity to get involved. That could for example be a contribution to the planning of the actual meeting, or some student or social events around it, which of course works well if the meeting is happening close to where you live. Another option is to volunteer your time during the conference. At EGU, my reporter role is a voluntary gig that I was more than happy to apply for. I’ve been interested in science communication for a while, so it seemed like a great opportunity to try out what it’s like being an “actual” reporter, and write about things way outside of my field. Plus, I might meet some famous reporters and bug them with lots of questions if I can – what’s not to like? The networking aspect opens up another topic:

Bring business cards

You might think that as a student why would I need a business card? Turns out it’s maybe even more important as a student than at a later stage (despite the fact that you don’t have a business…). Networking is all about being interested in other people, them being interested in you, and most importantly to leave a lasting impression. You never know when you might meet a person again, and in what situation. That doesn’t just apply to professionals in your field who are higher up the food chain, but even more so to your fellow students. They will be your future colleagues, and relationships between colleagues – even in different disciplines – can go a long way. I’ve been to many conferences before, and never thought about the business card thing. Man, do I wish I had. How many times have you been at a conference, awkwardly scribbling down somebody’s email address on a random piece of paper, only to lose it or to be unable to read your own writing after the fact? Business cards are a simple, tidy way to keep track of all the people you meet over the course of a conference, and a great way for them to remember you, too.

Wear your name badge somewhere easily visible

When I went to my first conference as a wee Master’s student, I thought it was maybe not super fashionable how everyone runs around with a badge around their neck. Turns out it’s actually super important. You want people you meet to have a visual of your name, to help you to leave a potentially lasting impression. That applies even more when you have somewhat complicated/foreign/rare name (I can’t expect non-German speakers to automatically make the connection from the spoken “Ka-tee” to the written “Kathi”, but I also refuse to anglicize my name. The name tag does help…). Also, for the slightly not so tall ones among us, it’s good to tie a knot into the lanyard or pin your badge to the side of your scarf or the collar of your shirt. Nothing more awkward than somebody having to bent down in front of your crotch to read your name…

Follow up

That one is a simple one – when you meet somebody interesting make sure to follow up with a short email on the day, just to refresh their memory. Following up, of course, requires some time in the evening set aside for that purpose, which leads to this:

Say no

Sometimes you’ll have to say no. There are so many things going on at conferences, from project meetings through evening receptions and dinners/drinks with old and new friends. Once in a while it’s good to say no. Set aside 1-2 hours in the evening to be able to wind down, process all the awesome experiences, and follow up on anything that the day brought (see Follow up).

Say yes

 Sometimes you’ll have to say yes. There will always be surprises, opportunities you didn’t expect. Show your face at the reception you’ve been invited to, even if it’s only for an hour or so. Go to sessions that you wouldn’t usually go to because it’s completely out of your field. I went to a lunchtime presentation about Spacecraft Landing Site Identification on Mars at a conference a few years ago, and learned that they use some of the same methodology that I use, despite a complete lack of overlap of my research with theirs. How cool is that? For this EGU, I highly recommend socializing with some fellow early career cryosphere people at our “Icy Outing” (more info here)!

Last but not least, the most important thing:

Have fun!

Yes, the conference is the reason why your supervisor paid for your flight, your hotel, and your food. But that doesn’t mean that you have to exhaust yourself to the point of collapse by day 3, when the conference lasts for another 2 days. Instead, pick a morning or afternoon with somewhat less relevant sessions and explore Vienna. Go to a museum. Take in all the history. Walk in Empress Sisi’s footsteps. Or do some shopping for the upcoming summer. Sit down in one of the many amazing coffee shops and enjoy your obligatory “Wiener Melange”. Use some time to catch up with old friends at a “Heuriger” or grab some food. If you don’t know what any of these words mean, look them up right now! Another great thing to do is spending some time getting to know new people. At a conference a few years ago, I went to a tweet-up, for example. Someone had booked a table at a pub close to the convention center, and invited fellow science-y social media people to meet up, where people only knew each other from Twitter or their respective blogs.

Doing all these things is a great way to wind down a bit (see Say no), to be refreshed after a little break and to take in more science in the following sessions. Conferences are so much more fun if you put a little bit of effort into spending time away from the meeting itself! I can’t wait to learn about more exciting science, meet fascinating people, and catch up with old and new friends during EGU!­

(Modified from a post originally published on Oct 26, 2014 on http://volcano-diaries.blogspot.com)

Edited by Sophie Berger, Emma Smith and Nanna Karlsson


Kathi Unglert is a PhD student in volcanology at the University of British Columbia, Vancouver. Her work looks at volcanic tremor, a special type of earthquake that tends to happen just before or during volcanic eruptions. She uses pattern recognition algorithms to compare tremor from many volcanoes to identify systematic similarities or differences. This comparison may help to determine the mechanisms causing this type earthquake, and could contribute to improved eruption forecasting. You can find her on Twitter (@volcanokathi) or read her volcano blog.profile_highres_EarthMatters_light

Image of the Week — AGU Fall Meeting 2015

Image of the Week — AGU Fall Meeting 2015

The American Geophysical Union (AGU) Fall Meeting, which takes place every December in  San Francisco is ending today.

With more than 24 000 attendees, 14 000 poster presentations and 7 000 talks, the AGU meeting is the largest conference on geophysical sciences in the World.

The cryosphere is one the topics covered by the meeting and we hope that this year edition was a fruitful for every participant.

Busy poster session on the Cryosphere. (Credit: Konstantinos Petrakopoulos)

Busy poster session on the Cryosphere. (Credit: Konstantinos Petrakopoulos)



Follow

Get every new post on this blog delivered to your Inbox.

Join other followers:
